Product Introduction
The Bently Nevada 3500/22-01-03-00 Transient Data Interface Module is an advanced industrial component designed for high-speed data acquisition in critical machinery monitoring applications. This product plays a key role in capturing transient signals, which include vibrations, pressure fluctuations, and temperature changes, making it an essential tool for predictive maintenance and real-time equipment health monitoring.
Specifically engineered for environments that demand precise, high-frequency data collection, the 3500/22-01-03-00 module integrates seamlessly with Bently Nevada’s comprehensive 3500 series to deliver a reliable solution for industrial equipment monitoring. The module enables operators to track potential failures and take corrective actions before they lead to costly downtime or catastrophic failures.
Product Specifications
| Specification | Details |
|---|---|
| Dimensions (L x W x H) | 241.3 x 24.4 x 241.8 mm |
| Weight | 0.91 kg |
| Input Voltage | 24V DC ± 10% |
| Operating Temperature Range | -40°C to +85°C |
| Input Channels | 8 differential or 16 single-ended |
| Communication Protocols | Modbus, Ethernet, RS-485 |
| Data Sampling Rate | 100 kHz |
| Accuracy | ±0.1% |
| Protection | IP20 rated |
| Mounting | DIN rail mounting |
Product Applications
The Bently Nevada 3500/22-01-03-00 Transient Data Interface Module is primarily used in high-stakes industries where equipment uptime is critical. Some of the key applications of this product include:
-
Power Generation
The module helps monitor turbines, compressors, and other critical machinery within power plants, ensuring uninterrupted service and preventing unforeseen failures. -
Oil and Gas
In oil refineries and offshore rigs, this module captures transient data for monitoring equipment such as pumps, compressors, and drilling machinery. -
Mining and Heavy Industry
In mining operations, where large machines operate under harsh conditions, the 3500/22-01-03-00 ensures that potential issues are identified before they lead to machine breakdowns. -
Automotive Manufacturing
High-precision manufacturing equipment in the automotive sector benefits from the transient data capture provided by the module, helping to maintain efficiency and avoid downtime. -
Aerospace
Aerospace manufacturers use the module to monitor vital equipment, ensuring components like turbines and propulsion systems are running at optimal conditions.
Product Advantages
-
High-Speed Data Acquisition
With a 100 kHz data sampling rate, this module ensures real-time capture of critical transient signals, which is crucial for early detection of faults. -
Multiple Channel Inputs
The module supports up to 8 differential or 16 single-ended input channels, allowing users to collect extensive data from multiple machines simultaneously. -
Wide Operating Temperature Range
Designed to function between -40°C and +85°C, the module is robust enough to handle extreme environmental conditions found in heavy industrial settings. -
Compact and Lightweight Design
With a compact size (241.3 x 24.4 x 241.8 mm) and a weight of just 0.91 kg, the module is easy to install even in space-constrained areas. -
Seamless Integration
Supporting popular communication protocols like Modbus, Ethernet, and RS-485, this module can easily integrate with existing industrial control systems. -
Durable Protection
Rated IP20, the module provides adequate protection against dust, ensuring its longevity and reliability in various industrial applications. -
Predictive Maintenance
By monitoring transient data, the module enables operators to predict and prevent machine failures, leading to reduced downtime and maintenance costs. -
Easy Installation
Designed for DIN rail mounting, this module simplifies the installation process, allowing for quick and efficient integration into control panels.
FAQ
Q1: What is the function of the Bently Nevada 3500/22-01-03-00 module?
A1: This module is designed to capture and transmit transient data from machinery to facilitate predictive maintenance and real-time monitoring.
Q2: What kind of data does this module capture?
A2: The module captures transient signals such as vibrations, pressure changes, and temperature fluctuations to detect anomalies in machinery performance.
Q3: Can this module operate in harsh environments?
A3: Yes, it is designed to withstand extreme conditions, with an operating temperature range from -40°C to +85°C and an IP20 rating for protection against dust.
Q4: How many input channels does the module support?
A4: The module supports 8 differential or 16 single-ended input channels, providing flexibility for monitoring various machinery.
Q5: What are the communication options available for this module?
A5: The module supports Modbus, Ethernet, and RS-485 protocols, ensuring easy integration with existing systems.
Q6: Is the module compatible with other Bently Nevada products?
A6: Yes, it is fully compatible with other components in the Bently Nevada 3500 series, providing a unified solution for machinery monitoring.
Q7: What is the data sampling rate of this module?
A7: The module offers a high-speed data sampling rate of 100 kHz, allowing for accurate and timely detection of transient events.
Q8: How accurate is the data captured by this module?
A8: The module provides an accuracy of ±0.1%, ensuring reliable and precise data collection for analysis.
Q9: What mounting option does this module support?
A9: The Bently Nevada 3500/22-01-03-00 module is designed for DIN rail mounting, making installation straightforward and secure.
Q10: What is the weight of the module?
A10: The module weighs 0.91 kg, making it lightweight and easy to integrate into industrial control systems.
