Product Introduction
The Bently Nevada 3500/25 128075-01E Slot Cover is a critical accessory designed for use within the Bently Nevada 3500 Series Machinery Protection System. Though seemingly simple in function, the slot cover plays an essential role in maintaining proper airflow, safety, EMC shielding, and dust protection within the 3500 rack system.
When a monitoring slot is not populated with an active module, this 128075-01E slot cover is installed to close the gap, preventing exposure to internal components and ensuring the rack complies with environmental protection and cooling requirements. It’s particularly important in industrial applications where vibration, dust, humidity, and electrical noise are present.
Constructed with durable, lightweight material and built to exacting Bently Nevada rack standards, the 3500/25 128075-01E ensures system integrity and longevity, even in harsh environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Slot Cover Panel |
| Model Number | 3500/25 |
| Part Number | 128075-01E |
| Function | Unused slot protection in 3500 rack; supports cooling, shielding, safety |
| Compatibility | All standard Bently Nevada 3500 racks |
| Material | Industrial-grade thermoplastic or coated aluminum |
| Mounting | Tool-free snap-in or screw-secured depending on rack design |
| Environmental Rating | IP20 when installed; not for standalone use |
| Certifications | RoHS compliant; CE compliant as part of complete rack system |
| Operating Temperature | -30°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Tolerance | 5%–95% non-condensing |
| Dimensions (W × H × D) | 119.9 x 24.4 x 256.5 mm |
| Weight | 0.34 kg |
| Included Hardware | May include snap tabs or screws depending on system type |
Applications
The 128075-01E slot cover is a small but critical component of the 3500 Series rack system and is used in the following applications:
-
Industrial Monitoring Racks
Fills unoccupied module slots to ensure optimal airflow and prevent dust buildup. -
Offshore and Marine Systems
Protects sensitive rack internals from corrosive environments and water vapor intrusion. -
Power Generation Plants
Maintains system thermal dynamics in turbine monitoring and generator diagnostic racks. -
Oil & Gas Refineries
Keeps rack internals clean and EMI-shielded in electrically noisy refinery control rooms. -
Factory Automation Panels
Prevents accidental exposure or damage to backplane interfaces in high-vibration machinery panels. -
Process Control Cabinets
Ensures compliance with cabinet-level safety and electromagnetic shielding standards.
Product Advantages
-
Environmental Protection
Shields rack internals from dust, debris, humidity, and contact, especially in harsh environments. -
Improved Airflow and Cooling
Maintains proper airflow across installed modules, improving cooling efficiency. -
EMC Compliance
Helps maintain shielding and EMI control across the 3500 rack system. -
Mechanical Safety
Prevents accidental contact with powered backplane terminals or communication traces. -
Durable and Lightweight
Manufactured with resilient industrial-grade material that withstands vibration and temperature variation. -
Easy Installation
Tool-free or minimal-tool installation allows for quick maintenance or reconfiguration of the rack. -
Cost-Effective
An inexpensive component that protects significantly more valuable monitoring assets. -
Universal Compatibility
Works across all standard Bently Nevada 3500 Series racks and monitoring enclosures.
Frequently Asked Questions (FAQ)
1. What is the primary function of the 128075-01E slot cover?
It protects unused slots in the 3500 Series rack by shielding internal components and maintaining system airflow.
2. Is it required to install a slot cover if a module is missing?
Yes, Bently Nevada recommends covering all empty slots to maintain cooling and prevent dust or interference.
3. Can this slot cover be reused?
Yes, it can be removed and reinstalled multiple times without degradation if handled properly.
4. Is it compatible with older versions of the 3500 rack?
Yes, the 128075-01E is backward-compatible with standard Bently Nevada 3500 racks.
5. Does the cover support EMC shielding?
While not an active shield, it contributes to overall electromagnetic compliance by closing gaps.
6. Is special hardware needed to install it?
Typically no. Most versions include snap-in features or simple fastening screws.
7. What material is it made from?
It’s typically constructed from thermoplastic or coated aluminum for strength and lightness.
8. Does it affect the performance of adjacent modules?
No, it helps optimize airflow, which may improve the thermal performance of neighboring modules.
9. Is it flame-retardant?
Yes, the materials used comply with flame resistance standards appropriate for industrial electronics.
10. Can it be used outside of Bently Nevada systems?
It is specifically designed for Bently Nevada 3500 Series racks and is not intended for third-party systems.
