Product Overview
The Bently Nevada 3500/32-01-01 149986-02+125720-01 4-channel Relay Module is designed for the 3500 Series Machinery Protection System to provide reliable relay outputs for alarm and trip signals. It enables the system to interface with external devices, allowing operators to respond to critical machinery conditions.
Key Features
-
Four independent relay channels for alarm and trip signals
-
Part of the Bently Nevada 3500 Series Machinery Protection System
-
Configurable for different relay functions
-
High reliability in harsh industrial environments
-
Compact, rack-mounted design for easy integration
-
LED indicators for channel status and diagnostics
-
Supports integration with 3500 series monitoring modules
Technical Specifications
| Specification | Details |
|---|---|
| Model | 3500/32-01-01 |
| Type | 4-channel Relay Module |
| Compatible System | Bently Nevada 3500 Series Machinery Protection System |
| Number of Channels | 4 |
| Relay Contact Type | SPDT (Single Pole Double Throw) |
| Maximum Switching Voltage | 250 VAC / 30 VDC |
| Maximum Switching Current | 5 A |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Indicators | Channel status LEDs |
| Mounting | 3500 series rack |
| Dimensions | 241 x 24.4 x 242 mm |
| Weight | 0.7 kg |
Frequently Asked Questions (FAQ)
1. What is the main function of the 3500/32-01-01 module?
It provides four independent relay channels for alarm and trip outputs in the 3500 system.
2. How many channels does it support?
It supports 4 independent relay channels.
3. What type of relay contacts does it use?
It uses SPDT (Single Pole Double Throw) relay contacts.
4. What is the maximum switching voltage and current?
The relays can handle up to 250 VAC or 30 VDC at 5 A.
5. What is the operating temperature range?
It operates reliably between 0 °C and +60 °C.
6. Does the module have indicators?
Yes, it includes channel status LEDs for diagnostics.
7. Can this module be integrated with other 3500 series modules?
Yes, it integrates fully with other 3500 series monitoring modules.
8. What mounting options are available?
It mounts directly into a 3500 series rack.
Related Bently Nevada Modules
| Model | Description |
|---|---|
| 3500/32-01-02 | 4-channel Relay Module (alternate version) |
| 3500/32-02-01 | 8-channel Relay Module |
| 3500/32-03-01 | 4-channel Redundant Relay Module |
| 3500/32-04-01 | 6-channel Relay Module |
| 3500/32-05-01 | Relay Module with configurable delay |
| 3500/32-06-01 | High-capacity relay module |
