Product Introduction
The Bently Nevada 3500/32M 125720-02 4-Channel Relay Output Module is an advanced device in the Bently Nevada 3500 series, offering reliable and precise control over external equipment and processes. This module is designed for monitoring systems where immediate response and safe operation are essential. By providing four independent relay channels, it allows for the triggering of alarms, shutdown systems, or other critical control devices based on the data it receives from connected sensors or controllers.
The 3500/32M 125720-02 is ideal for use in industries such as oil and gas, power generation, and manufacturing, where real-time control and machinery protection are of the utmost importance. Its modular design enables easy integration into existing systems, offering flexibility and scalability to suit various industrial applications.
With its high reliability, fast relay switching, and robust design, the 3500/32M ensures that your operations run smoothly while protecting critical assets from damage or failure. This module is built to provide continuous performance, even in harsh environmental conditions, ensuring long-term durability and low maintenance.
Product Specifications
| Specification | Details |
|---|---|
| Dimensions (L x W x H) | 241 x 24.4 x 99.1 mm |
| Weight | 0.4 kg |
| Number of Channels | 4 Channels |
| Relay Type | SPDT (Single Pole Double Throw) |
| Relay Output Rating | 5A @ 30V DC, 1A @ 120/240V AC |
| Coil Voltage | 24V DC |
| Relay Switching Time | < 10 ms |
| Operating Temperature Range | -40°C to +70°C |
| Mounting | DIN Rail or Panel Mountable |
| Environmental Protection | IP20 |
| Isolation | 250V AC between channels |
| Power Supply | 24V DC ±10% |
| Status Indicator | LED indicators for each channel |
Product Applications
The Bently Nevada 3500/32M 125720-02 is highly versatile and can be employed in various industrial control and monitoring applications. Here are some of its primary uses:
-
Machinery Protection Systems
The 3500/32M is often integrated into machinery protection systems. It can trigger emergency shutdowns, activate alarms, or control cooling systems when monitored parameters exceed set thresholds, preventing equipment damage and downtime. -
Process Control Systems
This module plays a crucial role in process control applications, where it interacts with valves, pumps, fans, or other critical devices. By monitoring the process parameters and triggering relay outputs when necessary, the module ensures that processes operate efficiently and safely. -
Turbine Protection
In turbine protection systems, the 3500/32M module can instantly activate safety mechanisms when conditions exceed safe operating limits. This module ensures turbines are protected from excessive vibration or temperature fluctuations, preventing catastrophic failures. -
Alarm and Warning Systems
The 3500/32M is frequently used in alarm and warning systems. When abnormal conditions are detected, it triggers alerts or activates external devices, helping operators take immediate action and minimize risk. -
Data Acquisition Systems
In data acquisition applications, this module controls the activation of data logging equipment or connected systems. This is especially useful in high-priority situations where capturing real-time data is critical for operational decisions. -
Remote Monitoring
The module is also effective in remote monitoring and control systems. It can manage devices in remote locations, ensuring that the operations of critical infrastructure can be remotely controlled or monitored from a centralized system.
Product Advantages
-
Fast Relay Switching
The 3500/32M 125720-02 features a rapid relay switching time of less than 10 ms. This quick response time ensures that connected devices are activated immediately in response to monitored data, crucial for real-time machinery protection and control. -
Independent Channel Control
The module provides four independent relay channels, allowing for precise and flexible control over various external devices. Each channel can be configured to operate based on different parameters, offering customizable control for various applications. -
Wide Temperature Range
The 3500/32M operates across a broad temperature range of -40°C to +70°C, making it suitable for installation in extreme industrial environments. This ensures reliable performance in diverse settings, from chilled environments to high-temperature locations. -
Compact and Robust Design
Despite its small size of 241 x 24.4 x 99.1 mm, the 3500/32M is built to withstand the tough conditions of industrial environments. It offers long-term reliability with a rugged construction, ensuring minimal downtime and reduced need for maintenance. -
Electrical Isolation Between Channels
The module offers 250V AC isolation between each of its channels, protecting the system from electrical interference or surges. This feature ensures the safety of the system and prevents faults from propagating across channels. -
Easy Installation
The 3500/32M can be mounted on a DIN rail or directly onto a panel. This makes the installation process quick and easy, with minimal disruption to existing systems. -
LED Status Indicators
The module is equipped with LED indicators for each relay channel, providing clear feedback about the status of each relay. This allows operators to quickly assess the module’s operational state and make necessary adjustments or repairs.
