Product Overview
The Bently Nevada 3500/61 133924-01 TC Isolated External Termination Block is a key component in the 3500 Series machinery protection system. It is designed for use with the 3500/60 and 3500/61 Temperature Monitor Modules, providing isolated connections for thermocouple (TC) inputs to ensure accurate and reliable temperature monitoring in industrial environments.
Technical Specifications
Applications
-
Industrial Machinery Monitoring: Monitors critical equipment temperatures in power plants, oil & gas facilities, and manufacturing plants.
-
Vibration Monitoring Systems: Integrates with vibration monitoring systems to provide comprehensive machinery health data.
-
Process Control Systems: Ensures accurate temperature readings for process optimization and operational safety.
Advantages
-
Electrical Isolation: 250 Vdc isolation between channels protects against electrical noise and ground loops.
-
Easy Integration: Compatible with Bently Nevada 3500/60 and 3500/61 modules for seamless system integration.
-
Robust Design: Built to withstand harsh industrial environments, ensuring long-term reliability.
Frequently Asked Questions (FAQ)
-
What is the purpose of the 3500/61 133924-01 termination block?
It provides isolated connections for thermocouple inputs to the 3500/60 and 3500/61 modules. -
How does the isolation benefit the system?
It protects the monitoring system from electrical noise and ground loops, ensuring accurate readings. -
Can this termination block be used with other Bently Nevada modules?
It is specifically designed for use with the 3500/60 and 3500/61 modules. -
What types of thermocouples are supported?
Supports various thermocouple types, depending on the configuration of the connected module. -
Is the termination block suitable for hazardous environments?
Yes, it is designed for industrial environments; specific certifications should be verified for each application. -
How is the termination block mounted?
It is mounted using terminal strip connectors for secure and reliable connections. -
What is the weight of the termination block?
The termination block weighs approximately 0.91 kg. -
Are there different versions of this termination block?
Yes, similar models include versions with Euro-style connectors. -
Can the termination block be repaired if damaged?
It is recommended to replace damaged components to maintain system integrity. -
Where can I purchase this termination block?
Contact Us.
Related Models
| Model Number | Description | Connector Type | Isolation | Compatibility |
|---|---|---|---|---|
| 133908-01 | RTD/TC Non-Isolated Termination Block | Terminal Strip | None | 3500/60, 3500/61 |
| 133916-01 | RTD/TC Non-Isolated Termination Block | Euro Style | None | 3500/60, 3500/61 |
| 133932-01 | TC Isolated Termination Block | Euro Style | 250 Vdc | 3500/60, 3500/61 |
| 133892-01 | Recorder Output Termination Block | Terminal Strip | None | 3500/61 |
| 133900-01 | Recorder Output Termination Block | Euro Style | None | 3500/61 |
| 00580442 | Connector Header, Internal Termination | 9-position | None | 3500/60 |
Popular Bently Nevada Models
| Model Number | Description | Input Type | Channels | Isolation | Weight | Dimensions (L×W×H) |
|---|---|---|---|---|---|---|
| 3500/60 | Temperature Monitor Module | RTD/TC | 6 | None | 1.8 kg | 241.3 × 24.4 × 241.8 mm |
| 3500/61 | Temperature Monitor Module | RTD/TC | 6 | None | 1.9 kg | 241.3 × 24.4 × 241.8 mm |
| 3500/22M | Transient Data Interface Module | – | – | – | 0.82 kg | 241.3 × 24.4 × 241.8 mm |
| 3500/20 | Rack Interface Module | – | – | – | 0.91 kg | 241.3 × 24.4 × 241.8 mm |
| 3500/32 | Channel Relay Module | – | – | – | 1.2 kg | 241.3 × 24.4 × 241.8 mm |
| 3500/15 | AC/DC Power Supply Module | – | – | – | 1.5 kg | 241.3 × 24.4 × 241.8 mm |
