Product Overview
The Bently Nevada 3500/92 133323-01 Communication Gateway I/O Module is a critical part of the 3500 Machinery Protection System, designed to provide communication between the 3500 rack and external plant control or monitoring systems. This module enables real-time data exchange through Modbus and Ethernet protocols, ensuring seamless integration with DCS, PLC, and SCADA systems. By delivering reliable access to protection status, alarms, and machine diagnostic data, it helps operators maintain high system availability and effective predictive maintenance.
Key Features
-
Supports Modbus RTU and Modbus/TCP protocols for versatile integration
-
Provides access to protection, status, and alarm data from the 3500 rack
-
Two communication ports for redundancy and configuration flexibility
-
Hot-swappable design ensures minimal downtime during replacement
-
Backplane-powered with no need for external supply
-
Compatible with all Bently Nevada 3500 rack types
-
Compact module footprint for efficient rack space usage
-
Industrial-grade reliability for harsh operating environments
Technical Specifications
| Item | Specification |
|---|---|
| Module Type | Communication Gateway I/O Module |
| Model Number | 3500/92 133323-01 |
| Protocols Supported | Modbus RTU (serial), Modbus/TCP (Ethernet) |
| Communication Ports | 2 (serial RS-232/RS-422/RS-485 and Ethernet) |
| Data Access | Protection status, measured values, alarms, configuration |
| Hot-Swappable | Yes |
| System Compatibility | All Bently Nevada 3500 racks |
| Power Supply | Provided via 3500 rack backplane |
| Operating Temperature | -30°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | Up to 95% non-condensing |
| Dimensions | 241 x 24.4 x 99.1 mm |
| Weight | 0.44 kg |
Industry Applications
-
Oil & gas production – real-time integration of equipment monitoring with DCS/SCADA
-
Petrochemical plants – machine health data for process optimization and safety
-
Power generation – seamless monitoring of turbines, generators, and auxiliary systems
-
Manufacturing – integration with PLC systems for equipment reliability
-
Pipeline operations – secure and remote monitoring through SCADA systems
Frequently Asked Questions (FAQ)
Q1: What is the function of the 3500/92 133323-01?
It serves as a gateway between the 3500 rack and plant control systems, transmitting machine protection and monitoring data.
Q2: Which communication protocols are supported?
It supports Modbus RTU over serial and Modbus/TCP over Ethernet.
Q3: How many communication ports are included?
It has two ports, supporting redundant communication or different protocol setups.
Q4: Can the module be hot-swapped?
Yes, it can be replaced without shutting down the 3500 system.
Q5: What type of data does it provide?
It provides access to protection status, alarm events, measured values, and configuration data.
Q6: Is it compatible with all 3500 racks?
Yes, it integrates with any standard Bently Nevada 3500 rack configuration.
Q7: Does it require an external power source?
No, it is powered through the rack backplane.
Q8: How does redundancy improve reliability?
Dual ports ensure that communication remains active even if one connection fails.
Q9: What industries benefit most from this module?
Industries such as oil & gas, petrochemicals, power generation, and pipelines.
Q10: What is its operating temperature range?
It operates between -30°C and +65°C.
