Product Description
The Bently Nevada 3500/94 VGA Display Monitor provides a clear and user-friendly interface for monitoring and configuring the 3500 Machinery Protection System. It displays real-time machinery parameters, status indications, and diagnostic data on a VGA screen. The module enhances operational visibility, enabling maintenance and operations teams to quickly identify and respond to machine conditions.
Technical Specifications
| Parameter | Description |
|---|---|
| Model | 3500/94 VGA Display Monitor |
| Part Numbers | 145988-01 + 147663-01 |
| Display Type | VGA, graphical user interface |
| Resolution | 640 x 480 pixels |
| Input Power | From 3500 rack |
| Communication Ports | Ethernet (optional), System Data Bus |
| Operating Temperature | 0°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 95% non-condensing |
| Dimensions | 241.3 x 24.4 x 241.8 mm |
| Weight | 0.73 kg |
| Mounting | 3500 rack front panel |
| Compliance | CE, CSA, FCC approvals |
Applications
-
Real-time machinery protection and monitoring in rotating equipment systems
-
Monitoring turbines, compressors, pumps, and motors
-
Integration with the Bently Nevada 3500 series system for centralized status visibility
-
Industrial environments requiring continuous machinery diagnostics
-
Display of vibration, temperature, and system alarm data
Advantages
-
High-clarity VGA interface for quick interpretation of data
-
Direct front-panel monitoring without external devices
-
Easy configuration and navigation through system data
-
Compatible with a wide range of 3500 modules
-
Rugged design suitable for demanding industrial environments
-
Improves maintenance efficiency by providing instant visual diagnostics
FAQ
Q1: What is the main function of the 3500/94 VGA Display Monitor?
A1: It provides visual access to system parameters, alarms, and diagnostics from the 3500 Machinery Protection System.
Q2: Can the display monitor be used independently?
A2: No, it requires connection to a 3500 rack system to function.
Q3: What type of data can be viewed on the monitor?
A3: It displays vibration levels, temperature readings, alarm statuses, and system health diagnostics.
Q4: How is the monitor powered?
A4: It is powered directly from the 3500 rack, requiring no separate power supply.
Q5: What is the resolution of the VGA display?
A5: The display provides 640 x 480 pixel resolution.
Q6: Is Ethernet communication supported?
A6: Yes, certain versions support Ethernet connectivity for remote monitoring.
Q7: Can the display be replaced without interrupting system operation?
A7: Yes, it can be hot-swapped without shutting down the system.
Q8: What industries commonly use this display monitor?
A8: Power generation, oil & gas, petrochemical, and heavy machinery industries.
Q9: What environmental conditions can it withstand?
A9: It operates between 0°C and +65°C, with storage down to -40°C.
Q10: Does it support multi-language display?
A10: Yes, the monitor supports multiple languages for global application.
