Product Introduction
The Bently Nevada 3500/94 161264-01 is a high-performance display module designed for monitoring and interacting with the 3500 Series Machinery Protection System (MPS). This display unit is engineered to provide clear, real-time visualization of machine parameters, including vibration, speed, and position data, enabling operators to make precise operational decisions. The module supports robust industrial environments and integrates seamlessly with other Bently Nevada 3500/94 system components, ensuring reliable performance in critical applications such as turbines, compressors, and generators.
This model features an intuitive interface with a touch-sensitive display and configurable readouts that enhance operational efficiency. It offers multiple communication ports for easy integration with existing plant networks and supports redundancy for increased system reliability.
Product Advantages
-
High Reliability: Designed for continuous 24/7 operation in demanding industrial environments.
-
Enhanced Visualization: Provides clear, high-contrast display for real-time monitoring of machine conditions.
-
Integration Flexibility: Supports multiple communication protocols, enabling smooth integration with other 3500 Series modules.
-
Operator-Friendly Interface: Intuitive touchscreen with customizable data layouts.
-
Redundancy Support: Compatible with dual-redundant systems for enhanced operational reliability.
-
Durable Design: Rugged construction to withstand vibration, temperature fluctuations, and electrical interference.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 3500/94 161264-01 |
| Type | Display Module |
| Display Type | LCD Touchscreen |
| Screen Size | 10.4 inches diagonal |
| Resolution | 640 x 480 pixels |
| Operating Temperature | -20°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Power Supply | 24 VDC ±10% |
| Power Consumption | 15 W |
| Cable length | 2 m |
| Weight | 0.5 kg |
| Communication Ports | Ethernet, RS-232, Modbus RTU |
| Mounting | Panel Mount |
| Compliance | CE, UL |
Product Applications
The 3500/94 161264-01 display module is widely used in industries requiring precise machine condition monitoring, including:
-
Gas and Steam Turbines: Provides real-time vibration and speed monitoring to prevent unscheduled shutdowns.
-
Compressors and Pumps: Enables continuous monitoring of rotating equipment to extend machinery life.
-
Generators: Helps in detecting abnormal conditions such as imbalance, misalignment, or bearing wear.
-
Petrochemical Plants: Monitors high-value rotating machinery for safety and efficiency.
-
Power Generation: Supports predictive maintenance strategies by displaying critical machine health parameters.
FAQ
Q1: What type of data can the 3500/94 161264-01 display module show?
A1: It displays vibration, speed, position, and alarm status of connected machinery, providing operators with actionable insights.
Q2: Can this display module operate in extreme temperatures?
A2: Yes, it operates between -20°C and 70°C, making it suitable for most industrial environments.
Q3: Is the display module compatible with all 3500 Series modules?
A3: It is compatible with 3500/94 system modules, ensuring seamless integration.
Q4: Does it support redundant systems?
A4: Yes, it supports dual-redundant systems for increased reliability.
Q5: How is the module mounted?
A5: It is designed for panel-mount installation.
Q6: What communication protocols are supported?
A6: Ethernet, RS-232, and Modbus RTU protocols are supported for flexible integration.
Q7: How much power does the module consume?
A7: The module consumes 15 W of power.
Q8: Is the touchscreen customizable for different operators?
A8: Yes, data layouts and readouts can be configured for operator preferences.
Q9: What is the expected lifespan of the display module?
A9: Designed for continuous 24/7 operation, the module has an expected lifespan of over 10 years under normal operating conditions.
Q10: What certifications does the module have?
A10: It complies with CE and UL standards, ensuring safety and reliability.
Recommended 6 Same-Series or Related Models
| Model Number | Description |
|---|---|
| 3500/94 147663-01 | Main Module |
| 3500/94 149356-01 | Display Router Box |
| 3500/94 146377-01 | Display Router Box |
| 3500/94 184826-01 | Main Module |
| 3500/94 120M8155-01 | Touch Screen Display |
| 3500/92 136188-02 | Ethernet/RS232 Modbus I/O Module |
Recommended 6 Popular Models from Bently Nevada
| Model Number | Description | Size (mm) | Weight (kg) | Voltage |
|---|---|---|---|---|
| 3300 XL 330103-17 | Proximity Probe | 50 x 30 x 25 | 0.25 | 24 VDC |
| 3500/22 131018-01 | Vibration Sensor Module | 180 x 120 x 70 | 1.8 | 24 VDC |
| 3500/33 119509-01 | Speed Sensor Module | 160 x 100 x 60 | 1.2 | 24 VDC |
| 3500/92 136188-02 | Ethernet/RS232 Modbus I/O Module | 200 x 150 x 80 | 1.5 | 24 VDC |
| 3500/94 184826-01 | Main Module | 260 x 220 x 80 | 2.0 | 24 VDC |
| 3500/60 136208-01 | Transducer Module | 170 x 130 x 60 | 1.4 | 24 VDC |
