Bently Nevada 60R/CHA02-00-0 Chassis 3U Panel

Product Introduction

The Bently Nevada 60R/CHA02-00-0 Chassis 3U Panel is a rugged, rack-mounted platform designed to house and protect Bently Nevada condition monitoring modules and associated electronics. Built for demanding industrial environments, this 3U chassis provides a secure and organized enclosure for vibration monitoring, machine protection, and process data acquisition systems. With options for country-specific electrical codes and configurable Safety Integrity Level (SIL) compliance, the 60R/CHA02-00-0 ensures global adaptability and safety assurance in mission-critical applications.

---

Technical Specifications

---

Applications

• Condition Monitoring Systems: Provides a secure rack enclosure for Bently Nevada vibration and machinery protection modules.

• Power Generation Plants: Centralizes turbine and generator monitoring electronics for easy maintenance.

• Oil & Gas Facilities: Houses monitoring equipment for compressors, pumps, and offshore platforms exposed to harsh conditions.

• Petrochemical and Refining Plants: Organizes and shields critical diagnostic modules from chemical exposure and electrical noise.

• Industrial Manufacturing: Suitable for high-vibration environments such as steel mills, paper mills, and mining operations.

• Safety-Critical Systems: SIL-rated configuration supports functional safety in high-risk applications.

---

Advantages

• Robust Mechanical Design: Heavy-duty aluminum chassis provides exceptional strength while maintaining lightweight portability.

• Scalable Architecture: Accommodates up to 8 modules, allowing expansion as monitoring needs grow.

• Enhanced Safety Compliance: Optional SIL 1 or SIL 2 configuration ensures reliable performance in safety-instrumented systems.

• Global Flexibility: Country-specific code options simplify compliance with regional electrical and safety standards.

• Efficient Power Distribution: Redundant 24 VDC backplane guarantees continuous operation even in the event of a power supply fault.

• Superior EMI/RFI Protection: Low-noise grounding and shielded backplane minimize electromagnetic interference.

• Easy Installation and Maintenance: Standard 19-inch rack size and front-panel access streamline setup and servicing.

• Optimal Cooling Design: Passive airflow with optional fan tray ensures stable operation in extended temperature ranges.

---

FAQ

1. What is the maximum number of monitoring modules the 60R/CHA02-00-0 chassis can support?
   The chassis can house up to 8 Bently Nevada monitoring or protection modules depending on system configuration.

2. What power supply is required for the integrated backplane?
   The chassis operates with a redundant 24 VDC input, ensuring uninterrupted power for all installed modules.

3. Does the chassis meet specific Safety Integrity Level standards?
   Yes, it can be configured for SIL 1 or SIL 2 compliance to meet safety-instrumented system requirements.

4. Is the chassis compatible with all Bently Nevada condition monitoring modules?
   It is designed to support a wide range of Bently Nevada modules, including vibration, temperature, and process interface cards.

5. What communication interfaces are supported through the backplane?
   The backplane supports Ethernet, Modbus, and proprietary Bently Nevada communication protocols for seamless system integration.

6. Can the chassis be installed in high-vibration environments?
   Yes, it withstands continuous vibration of 5 g from 5–2000 Hz and shock up to 30 g, making it suitable for heavy industry.

7. How is grounding handled to prevent electrical noise?
   A high-conductivity copper grounding bus provides low-impedance grounding for superior EMI/RFI suppression.

8. Does the chassis require active cooling?
   The passive airflow design is sufficient for most applications, but an optional fan tray can be installed for additional cooling if required.

9. Are country-specific electrical codes available?
   Yes, models can be ordered to comply with North American, European, or Asia-Pacific electrical standards.

10. What is the recommended operating temperature range?
    The chassis is designed for –20 °C to +70 °C operation, ensuring stable performance in both indoor and outdoor installations.

---
