Bently Nevada 84145-01 78462-01 XDCR I/O And Record Terminal

Product Introduction

The Bently Nevada 84145-01 / 78462-01 XDCR I/O and Record Terminal is a specialized interface module designed for advanced machinery protection and condition monitoring systems. Serving as a critical bridge between transducers (XDCR) and the monitoring rack, this module provides secure signal termination, conditioning, and routing for a variety of sensor inputs, such as proximity probes, velocity sensors, and accelerometers. By delivering reliable signal integrity and simplified field wiring, the 84145-01 / 78462-01 ensures precise data acquisition for Bently Nevada monitoring platforms like the 3500 series. Its rugged construction and noise-resistant design make it ideal for demanding industrial environments, supporting accurate recording and diagnostics of rotating equipment.

Technical Specifications

Applications

The 84145-01 / 78462-01 XDCR I/O and Record Terminal is used wherever reliable transducer signal management and recording are essential:

• Power Generation Plants: Interfaces proximity probes and velocity sensors for turbines, generators, and auxiliary equipment.

• Oil & Gas Facilities: Provides secure and noise-free transducer connections for compressors, pumps, and offshore platforms.

• Petrochemical Industry: Records and routes critical sensor signals in refineries and chemical process units.

• Steel and Mining Operations: Handles transducer signals for large motors, crushers, and conveyors.

• Marine and Offshore Applications: Maintains stable signal integrity in high-vibration, high-humidity conditions.

• Industrial Automation: Ensures accurate monitoring of machinery in factory and process automation systems.

Advantages

• High Signal Integrity: Maintains clean, noise-free signals from sensors to monitoring racks.

• Flexible Input Capability: Supports proximity probes, accelerometers, and velocity transducers.

• Integrated Protection: Built-in over-voltage and reverse-polarity protection safeguards connected equipment.

• Ease of Installation: Removable terminal blocks simplify wiring and field maintenance.

• Superior Isolation: Channel-to-channel and channel-to-ground isolation reduce electrical interference.

• Robust Construction: Designed for continuous operation in harsh industrial environments.

• Efficient Diagnostics: Front-panel LED indicators provide immediate status feedback.

• Wide Operating Range: Performs reliably across a broad temperature and environmental spectrum.

FAQ

1. What types of transducers can be connected to the 84145-01 / 78462-01 module?
   It supports proximity probes, velocity sensors, and accelerometers commonly used in machinery monitoring.

2. What is the input voltage range for transducer signals?
   The module accepts ±24 VDC maximum sensor supply.

3. Does the module provide isolation between channels?
   Yes, it provides both channel-to-channel and channel-to-ground isolation to ensure signal integrity.

4. Can this module be mounted on a DIN rail as well as in a rack?
   Yes, it supports direct rack insertion or DIN rail mounting with an adapter.

5. What level of noise immunity does the module offer?
   It provides greater than 60 dB common-mode rejection for excellent noise suppression.

6. Is the module equipped with protection features?
   Yes, it includes over-voltage and reverse-polarity protection to prevent damage.

7. How does the module indicate operational status?
   Front-panel LEDs display input and output status for quick diagnostics.

8. What is the typical operating temperature range?
   It operates reliably from –30 °C to +65 °C.

9. Is the module compatible with Bently Nevada 3500 monitoring systems?
   Yes, it integrates seamlessly with Bently Nevada 3500 racks and associated monitoring equipment.

10. What type of connectors are used for field wiring?
    The module uses removable terminal blocks with screw clamps for secure and easy wiring.
