Bently Nevada 9200-01-01-11-04 Product Introduction
The Bently Nevada 9200-01-01-11-04 is a high-performance vibration monitoring module designed for critical machinery protection and condition monitoring. This module is part of the Bently Nevada 3500/92 series, which is widely used in industries such as oil and gas, power generation, and chemical processing. It provides reliable and accurate vibration measurements, ensuring the safe and efficient operation of rotating equipment. The 9200-01-01-11-04 module is engineered to meet stringent industry standards, offering robust performance in harsh environments.
Product Parameters
The technical specifications of the Bently Nevada 9200-01-01-11-04 are as follows:
| Parameter | Specification |
|---|---|
| Input Channels | 4 channels (accepts proximity probe signals) |
| Frequency Range | 0.5 Hz to 10 kHz |
| Dynamic Range | 0 to 200 mV/mm (peak-to-peak) |
| Output Signals | 4–20 mA, buffered sensor signals |
| Power Supply | 18–30 VDC |
| Operating Temperature | -30°C to +70°C |
| Sensor diameter | 41.4mm |
| Weight | 0.3 kg |
| Compliance | ATEX, IECEx, CSA, FM (hazardous area certified) |
Product Applications
The Bently Nevada 9200-01-01-11-04 is primarily used for:
-
Turbine Monitoring: Ensures safe operation of steam and gas turbines by detecting abnormal vibrations.
-
Compressor Protection: Monitors vibration levels in centrifugal and reciprocating compressors.
-
Pump Systems: Detects misalignment, imbalance, and bearing wear in critical pumps.
-
Fan and Motor Monitoring: Provides early warning of mechanical faults in industrial fans and motors.
-
Power Generation: Used in hydroelectric and thermal power plants for machinery health assessment.
Product Advantages
-
High Accuracy: Delivers precise vibration measurements for early fault detection.
-
Robust Design: Built to withstand extreme temperatures and harsh industrial environments.
-
Flexible Integration: Compatible with Bently Nevada 3500 rack systems for seamless data acquisition.
-
Certified Safety: Complies with ATEX and IECEx standards for hazardous areas.
-
Low Maintenance: Solid-state design ensures long-term reliability with minimal servicing.
Frequently Asked Questions (FAQ)
-
What is the purpose of the 9200-01-01-11-04 module?
It is a 4-channel vibration monitor for machinery protection and condition monitoring. -
Can this module be used in explosive environments?
Yes, it is ATEX and IECEx certified for hazardous areas. -
What types of sensors are compatible with this module?
It accepts signals from proximity probes (eddy current sensors). -
What is the operating voltage range?
It operates on 18–30 VDC. -
How many output signals does it provide?
It offers 4–20 mA outputs and buffered sensor signals. -
What is the frequency response range?
0.5 Hz to 10 kHz. -
Is this module compatible with the Bently Nevada 3500 system?
Yes, it is designed for integration with the 3500 rack. -
What are the Sensor diameter and weight of the module?
41.4mm, 3 kg. -
Does it require regular calibration?
Periodic calibration is recommended for optimal performance. -
Can it detect bearing defects?
Yes, it can identify bearing wear through vibration analysis.
