Product Introduction
The Emerson KJ3206X1-BA1 Power Supply Module is a high-reliability component engineered for use within Emerson’s DeltaV distributed control systems (DCS). Designed to provide stable and regulated power to the I/O subsystems, this power supply module plays a crucial role in ensuring uninterrupted process automation operations.
Featuring advanced diagnostics, rugged construction, and a compact footprint, the KJ3206X1-BA1 is ideal for mission-critical environments such as oil & gas, power generation, chemical processing, and other industrial automation sectors. Its modular design facilitates quick installation and easy replacement, contributing to reduced maintenance time and enhanced system uptime.
Product Specifications
| Parameter | Details |
|---|---|
| Model | KJ3206X1-BA1 |
| Brand | Emerson |
| Series | DeltaV |
| Function | System Power Supply Module |
| Input Voltage | 24 VDC (Nominal) |
| Input Voltage Range | 18 – 32 VDC |
| Output Voltage | 24 VDC Regulated |
| Output Power Capacity | Up to 100W |
| Power Supply Type | Redundant capable, hot-swappable |
| Efficiency | >85% |
| Status Indicators | LED indicators for power status and fault diagnosis |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% – 95% RH (non-condensing) |
| Mounting Type | Rack/DIN rail mount |
| Certifications | CE, CSA, UL, ATEX |
| Dimensions | 138 x 81 x 43 mm |
| Weight | 1.21 kg |
Product Applications
The KJ3206X1-BA1 is deployed across various industrial sectors where continuous power availability and system redundancy are vital. Typical applications include:
-
Oil and Gas Facilities: Ensures uninterrupted control system power in offshore and onshore platforms.
-
Chemical Processing Plants: Powers critical I/O modules for batch and continuous processes.
-
Power Generation Plants: Maintains control operations in both fossil and renewable generation facilities.
-
Pharmaceutical Industry: Supports validated control environments for GMP compliance.
-
Water Treatment Plants: Powers automation systems for municipal and industrial water systems.
-
Pulp and Paper Mills: Enables smooth operations of process and machine controls.
Product Advantages
-
High Reliability: Built to Emerson’s industrial standards for consistent performance under harsh conditions.
-
Redundancy Support: Enables dual power module configurations for fault-tolerant systems.
-
Hot-Swappable: Can be replaced without shutting down the system, minimizing operational disruptions.
-
Compact Design: Saves panel space while delivering high performance.
-
Advanced Diagnostics: On-module LED indicators offer real-time operational feedback.
-
Robust Environmental Ratings: Operates effectively in extreme temperatures and humidity levels.
-
Integration Ready: Seamlessly integrates into DeltaV systems with native configuration support.
-
Ease of Maintenance: Modular design allows quick access and minimal servicing requirements.
