Product Overview
The Emerson KJ4001X1-CD1 is a DeltaV redundant power module designed to provide reliable and uninterrupted power to DeltaV™ control systems. By operating in a redundant configuration, it ensures system availability and prevents downtime in the event of a primary power supply failure. Built with Emerson’s proven industrial-grade technology, the KJ4001X1-CD1 delivers stable, regulated power for controllers, I/O modules, and other DeltaV components in demanding industrial environments.
Key Features
-
Redundant power supply design for maximum reliability
-
Provides stable, regulated power to DeltaV systems
-
Automatic switchover to backup supply in case of failure
-
Compact and modular design for easy installation
-
Built-in protection against over-voltage, over-current, and short-circuit conditions
-
Designed for continuous operation in mission-critical applications
Technical Specifications
| Item | Specification |
|---|---|
| Model Number | KJ4001X1-CD1 |
| Manufacturer | Emerson |
| Product Type | Redundant Power Module |
| System Compatibility | Emerson DeltaV™ control systems |
| Input Voltage | 24 VDC nominal (19–30 VDC range) |
| Output Voltage | 24 VDC regulated |
| Output Power | Up to 30 W (system dependent) |
| Redundancy Mode | Supports 1:1 redundancy with automatic failover |
| Protection Features | Over-voltage, over-current, and short-circuit protection |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Humidity | 5–95% non-condensing |
| Dimensions | 110 x 100 x 30 mm |
| Weight | 0.3 kg |
| Certifications | CE, UL, CSA, RoHS |
Industry Applications
-
Power Generation – ensures redundant power for automation systems
-
Oil & Gas – maintains continuous DeltaV system operation in critical processes
-
Petrochemical & Chemical – prevents downtime with backup power functionality
-
Manufacturing – supports reliable process monitoring and control
-
Water & Wastewater – ensures uninterrupted SCADA and process automation
Advantages
-
Redundant design enhances system availability
-
Automatic switchover prevents system disruption during faults
-
Industrial-grade reliability in harsh operating environments
-
Compact size conserves cabinet space
-
Simple integration into DeltaV architectures
-
Long service life with minimal maintenance
Frequently Asked Questions (FAQ)
Q1: What is the main function of the KJ4001X1-CD1?
It provides redundant, regulated power for Emerson DeltaV systems.
Q2: How does redundancy work in this module?
It operates in a 1:1 redundant pair, automatically switching to the backup unit if the primary fails.
Q3: What is the input voltage requirement?
24 VDC nominal, with an acceptable range of 19–30 VDC.
Q4: What output voltage does it provide?
It supplies a regulated 24 VDC output.
Q5: What is the maximum output power?
Up to 30 W, depending on the system configuration.
Q6: What protection features are included?
It has built-in over-voltage, over-current, and short-circuit protection.
Q7: What is the operating temperature range?
0 °C to +60 °C.
Q8: Can it be hot-swapped?
Yes, it is designed for quick replacement without system shutdown.
Q9: Is it compatible with all DeltaV systems?
Yes, it is fully integrated with Emerson DeltaV architectures.
Q10: What certifications does it carry?
It meets CE, UL, CSA, and RoHS standards.
