Product Introduction:
The Emerson KJ4001X1-NB1 LocalBus Dual Left Cable Extender is an essential accessory designed for use within Emerson’s DeltaV distributed control system architecture. It serves as a cable extender for the LocalBus network, specifically engineered to extend the connection distances between DeltaV modules while maintaining signal integrity and reliability.
This dual left cable extender features a robust build and a dual cable outlet on the left side, enabling efficient and organized cable management in control cabinets or racks. Its design simplifies the process of expanding system configurations, allowing engineers and maintenance teams to adjust and optimize module placement without requiring complex rewiring.
Manufactured to endure the demanding conditions of industrial environments, the KJ4001X1-NB1 ensures stable and consistent communication between modules, contributing to overall system reliability and uptime.
Product Specifications:
| Parameter | Details |
|---|---|
| Product Name | Emerson KJ4001X1-NB1 LocalBus Dual Left Cable Extender |
| Manufacturer | Emerson |
| Product Type | LocalBus Cable Extender |
| Cable Orientation | Dual Left Cable Output |
| Compatible System | Emerson DeltaV Distributed Control System |
| Operating Temperature Range | -40°C to +70°C (-40°F to +158°F) |
| Storage Temperature Range | -40°C to +85°C (-40°F to +185°F) |
| Humidity Range | 5% to 95% Non-condensing |
| Dimensions (L x W x H) | 35 x 55 x 155 mm |
| Weight | 0.2 kg |
| Construction Material | Industrial-grade plastic and metal |
| Certifications | CE Certified |
Applications:
-
Extending LocalBus cable connections within Emerson DeltaV systems to facilitate flexible control cabinet configurations.
-
Allowing system designers to increase distance between modules without degrading signal quality.
-
Improving cable routing and organization within control racks.
-
Simplifying maintenance and future system upgrades by enabling modular system expansion.
-
Suitable for use in industries such as oil & gas, chemical processing, power generation, and manufacturing where DeltaV systems are deployed.
Product Advantages:
-
Extended Reach: Enables extension of LocalBus connections, supporting modular and flexible system architecture.
-
Signal Integrity: Maintains reliable data communication across extended cable lengths without signal loss.
-
Ease of Installation: Designed for plug-and-play operation; no specialized tools or complex setup required.
-
Durability: Constructed to operate reliably in harsh industrial environments with temperature extremes and humidity.
-
Improved Cable Management: Dual left cable design assists in organized routing and reduces cable clutter within control panels.
-
Compatibility: Fully compatible with DeltaV system components, ensuring seamless integration.
Frequently Asked Questions (FAQ):
-
What is the main function of the KJ4001X1-NB1?
It extends the LocalBus cable connections in DeltaV systems, allowing greater distance between modules. -
Can this extender be used with all DeltaV modules?
It is compatible with modules designed to connect via LocalBus within the DeltaV system. -
What is the maximum recommended cable extension using this product?
Cable extension limits depend on system design, but Emerson guidelines specify the maximum allowed lengths for LocalBus cables. -
Does the product require any power supply?
No, it operates as a passive cable extender and does not require additional power. -
How does the dual left cable design benefit system installation?
It allows for efficient cable routing to the left side, enabling cleaner and more manageable wiring layouts. -
Is the extender suitable for use in extreme temperature environments?
Yes, it is rated for operation between -40°C and +70°C, suitable for most industrial settings. -
Does using the extender affect data transmission speed?
When used within specified limits, it maintains full data transmission speeds without degradation. -
Are there any certifications for this product?
Yes, the extender is CE certified, meeting European safety and performance standards. -
What materials are used in manufacturing the extender?
It is constructed from high-quality industrial-grade plastic and metal components for durability. -
How difficult is installation for maintenance personnel?
The installation process is straightforward and designed to be performed quickly without specialized tools.
Recommended Related Models:
| Model | Description | Key Feature |
|---|---|---|
| KJ4001X1-NA1 | Horizontal LocalBus Dual Right Cable Extender | Dual right cable orientation |
| KJ4001X1-NB2 | LocalBus Dual Left Cable Extender (Vertical) | Vertical orientation for cable routing |
| KJ4001X1-NC1 | LocalBus Single Cable Extender | Single cable extension capability |
| KJ4002X1-NB1 | LocalBus Right Angle Cable Extender | Right angle cable extension |
| KJ4003X1-NB1 | LocalBus Ribbon Cable Extender | Supports ribbon cable types |
| KJ3100X1-NB1 | LocalBus Module Extension Kit | Kit for modular LocalBus expansions |
Popular Emerson Models:
| Model | Description | Application Area |
|---|---|---|
| KJ3102X1-BA1 | Analog Input Module with HART support | Process automation and signal acquisition |
| KJ3222X1-BA1 | Multi-channel Analog Input Module | Multi-channel analog processing |
| KJ3700X1-BA1 | Digital Output Module | Control of digital devices |
| KJ3740X1-BA1 | High-Speed Counter Module | Counting and timing applications |
| KJ3104X1-BA1 | Analog Output Module | Analog control signal output |
| KJ3705X1-BA1 | Communication Module | Protocol bridging and data exchange |
