Product Introduction
The Emerson KL2101X1-BB1 CHARM I/O Card is a key component in the DeltaV™ Electronic Marshalling architecture, designed to interface seamlessly with Characterization Modules (CHARMs). This module represents a significant innovation in field wiring strategy, allowing flexible signal characterization at the terminal level and greatly simplifying I/O design, expansion, and maintenance.
The KL2101X1-BB1 is designed to host and communicate with individual CHARM modules, enabling precise signal conditioning directly at the marshalling cabinet. Instead of routing signals to traditional I/O cards housed deep within a control system, the CHARM I/O Card brings that functionality closer to the field, allowing faster deployment, easier diagnostics, and modular system growth. This reduces project risk, shortens commissioning timelines, and improves operational reliability.
Product Specifications
| Parameter | Details |
|---|---|
| Product Name | KL2101X1-BB1 |
| Manufacturer | Emerson |
| Product Type | CHARM I/O Card |
| System Compatibility | DeltaV™ Electronic Marshalling |
| Channels Supported | Supports up to 96 CHARM modules |
| Signal Types | AI, AO, DI, DO, RTD, TC (via appropriate CHARM modules) |
| Communication Interface | Redundant Ethernet (DeltaV CHARM Smart I/O bus) |
| Power Supply | 24 VDC |
| Power Consumption | Approx. 7 W |
| Isolation | Channel-to-channel isolation via individual CHARMs |
| Mounting Type | DIN rail (35 mm standard rail) |
| Status Indicators | LED indicators for module health and communication |
| Operating Temperature Range | -40°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity Range | 5% to 95% (non-condensing) |
| Certifications | CE, CSA, UL, ATEX (when used with certified CHARMs) |
| Dimensions (H × W × D) | 144 × 42 × 106 mm |
| Weight | 0.454 kg |
Product Applications
The KL2101X1-BB1 CHARM I/O Card is tailored for demanding control system environments where flexibility, scalability, and efficient project execution are critical. Typical applications include:
-
Distributed Control Systems (DCS): Seamlessly integrates into DeltaV systems to provide modular I/O handling.
-
Chemical & Petrochemical Plants: Used for precise signal processing and monitoring in complex chemical processes.
-
Oil & Gas Facilities: Offers rugged field wiring solutions for upstream, midstream, and downstream systems.
-
Power Generation: Facilitates reliable and scalable control in thermal and renewable energy plants.
-
Pharmaceutical Industry: Enables rapid system validation and modular expansion during production scale-up.
-
Water and Wastewater Treatment: Delivers robust signal interface in harsh environmental conditions.
Product Advantages
-
Scalable Architecture: Each card supports up to 96 CHARM modules, allowing future expansion without reengineering the system.
-
Field-Level Signal Conditioning: With CHARMs directly on the marshalling panel, signal type selection and installation is fast and flexible.
-
Reduced Complexity: Significantly decreases wiring errors, cabinet space requirements, and system integration time.
-
Hot-Swappable CHARMs: Individual CHARM modules can be replaced under power, minimizing downtime.
-
Improved Diagnostics: Integrated LED indicators and smart communication allow fast fault identification and correction.
-
Redundancy-Ready: Compatible with redundant controller and network topologies, supporting high availability requirements.
-
Universal Support: Supports both analog and discrete signal types through compatible CHARMs, minimizing parts inventory.
-
Global Compliance: Certified for use in hazardous locations when used with approved CHARMs and enclosures.
Frequently Asked Questions (FAQ)
-
Q: What control platform is the KL2101X1-BB1 compatible with?
A: It is designed exclusively for the Emerson DeltaV™ system using Electronic Marshalling. -
Q: How many CHARM modules can a single KL2101X1-BB1 support?
A: One card can support up to 96 CHARMs. -
Q: Can I mix different types of CHARMs on one card?
A: Yes, you can mix analog, discrete, and specialty CHARMs on the same card. -
Q: Is the card hot-swappable?
A: The card itself is not hot-swappable, but individual CHARMs can be replaced while powered. -
Q: What kind of wiring does the card require?
A: Standard field wiring terminated at CHARM terminal blocks, with Ethernet connection for control communication. -
Q: Is this card suitable for hazardous area installations?
A: Yes, when installed with certified CHARMs and in appropriate enclosures, it can be used in hazardous areas. -
Q: How is communication handled?
A: Through redundant Ethernet connections on the DeltaV CHARM I/O network. -
Q: Does the card require firmware updates?
A: Yes, the card firmware may be updated via DeltaV Explorer to maintain compatibility and reliability. -
Q: What diagnostic features are built in?
A: LED indicators for health, communication, and power, along with DeltaV diagnostics. -
Q: Can this card be used in legacy DeltaV systems?
A: Only DeltaV systems that support Electronic Marshalling architecture can use the KL2101X1-BB1.
