Product Introduction:
The Emerson KL3103X1-BA1 Programmer Card is a specialized industrial automation component designed for system configuration, control logic programming, and interface integration within Emerson control platforms. Known for its high compatibility and robust construction, this programmer card plays a crucial role in programmable logic controller (PLC) environments, enabling precise interaction between hardware systems and control software.
This card is typically used to facilitate diagnostics, firmware updates, and system communication in Emerson’s distributed control systems (DCS). Its design ensures secure data transfer and quick synchronization with field devices, contributing to system reliability and ease of maintenance.
With its plug-and-play nature, the KL3103X1-BA1 supports seamless integration into racks and chassis units of Emerson control systems, making it ideal for process industries such as power generation, oil & gas, petrochemical, water treatment, and industrial manufacturing.
Product Specifications
| Parameter | Specification |
|---|---|
| Product Model | KL3103X1-BA1 |
| Product Type | Programmer Card |
| Brand | Emerson |
| Compatible Systems | Ovation™ Control System, Emerson DCS Platforms |
| Communication Interface | Serial/Parallel (model dependent) |
| Operating Voltage | 5 VDC (typical, backplane powered) |
| Power Consumption | ≤ 2.5 W |
| Data Transfer Rate | High-speed internal bus protocol |
| Memory Support | Integrated EEPROM and Flash |
| Diagnostics Capability | Yes |
| Operating Temperature Range | -20°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Mounting Type | Card Rack Mountable (standard backplane interface) |
| Dimensions (L x W x H) | 120 x 150 x 45 mm |
| Weight | 0.5 kg |
| Certification | CE, UL, RoHS Compliant |
| Enclosure Type | Open frame (for internal cabinet installation) |
Applications
-
Control System Programming: Used in configuring logic and communication settings for Emerson’s Ovation and other compatible DCS/PLC systems.
-
Field Diagnostics: Facilitates in-field troubleshooting, firmware diagnostics, and logic updates without dismantling the system.
-
Process Automation: Supports complex automation tasks in refineries, chemical plants, and manufacturing units.
-
Utility Management: Used in water and power management for system parameter tuning and real-time diagnostics.
-
Redundancy Systems: Plays a key role in high-availability redundant systems for seamless failover operation.
-
Integration Projects: Allows smooth data communication and synchronization between third-party I/O and Emerson platforms.
Product Advantages
-
Seamless Integration: Designed specifically to slot into Emerson systems without requiring special connectors or external power.
-
High Compatibility: Compatible with multiple Emerson automation systems including Ovation and legacy platforms.
-
Compact Form Factor: Space-efficient design allows deployment in space-constrained cabinet environments.
-
Diagnostics Ready: Built-in diagnostics features simplify maintenance and help minimize system downtime.
-
Robust Reliability: Designed to withstand industrial temperature and humidity conditions.
-
Longevity Support: Backed by Emerson’s extended product lifecycle support, ensuring long-term investment protection.
Frequently Asked Questions (FAQ)
-
What systems is the KL3103X1-BA1 compatible with?
It is compatible with Emerson’s Ovation DCS and other legacy platforms within their control architecture. -
Does the KL3103X1-BA1 require external power supply?
No, it is backplane-powered and does not need an external power input. -
Can I use this card in a redundant configuration?
Yes, it supports use in redundant systems for high availability and fail-safe operations. -
Is the card hot-swappable?
Hot-swapping depends on the system configuration; generally, it’s recommended to power down before replacement. -
What diagnostic tools does the card support?
It supports on-board diagnostics via system interface, allowing error logging and firmware validation. -
Does this product support firmware updates?
Yes, firmware updates can be deployed using this card via system software tools. -
Can I use third-party programming tools with it?
Emerson recommends using their native software tools to ensure full functionality and compatibility. -
Is there a risk of data loss during card replacement?
If performed correctly, the system retains configurations. A backup before replacement is always advised. -
What is the card’s weight?
0.5 kg. -
What certifications does the KL3103X1-BA1 carry?
It is CE certified, UL listed, and compliant with RoHS directives.
