Product Introduction
The Emerson VE4003S2B1 KJ4001X1-CA1 Analog Input Card is a high-performance module designed for integration into Emerson DeltaV systems. It provides precise and reliable analog signal acquisition for a wide range of industrial process control applications. This card supports multiple analog input channels and ensures accurate data conversion, making it ideal for environments where control accuracy and system reliability are critical.
Product Advantages
-
High-accuracy analog signal acquisition with low noise and minimal drift.
-
Compatibility with Emerson DeltaV automation systems for seamless integration.
-
Supports multiple input types, including voltage and current signals.
-
Robust construction for reliable operation in industrial environments.
-
Provides diagnostic feedback for easier maintenance and system monitoring.
-
Compact design allows flexible installation in control racks.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | VE4003S2B1 KJ4001X1-CA1 |
| Input Type | Analog (Voltage/Current) |
| Number of Channels | 4 or 8 channels depending on configuration |
| Accuracy | ±0.05% of full scale |
| Input Range | 0–20 mA, 4–20 mA, 0–10 V |
| Resolution | 16-bit |
| Response Time | 10 ms typical |
| Isolation | Channel-to-channel isolation provided |
| Communication Interface | DeltaV bus compatible |
| Operating Temperature | 0–60°C |
| Storage Temperature | -20–85°C |
| Humidity | 5–95% non-condensing |
| Dimensions | 107 x 41 x 105 mm |
| Weight | 0.18 kg |
| Power Supply | 24 VDC typical |
Product Applications
-
Industrial process monitoring and control.
-
Chemical, petrochemical, and refining process automation.
-
Oil and gas production and processing systems.
-
Power generation and distribution monitoring.
-
Water and wastewater treatment plants.
-
Any application requiring accurate analog signal acquisition for feedback loops.
FAQ
Q1: What types of analog signals does the VE4003S2B1 support?
A1: It supports standard voltage and current signals, including 0–10 V, 0–20 mA, and 4–20 mA.
Q2: How many input channels are available on this card?
A2: The card supports either 4 or 8 analog input channels, depending on the configuration.
Q3: What is the typical accuracy of the analog measurements?
A3: The measurement accuracy is ±0.05% of full scale.
Q4: Can the card operate in harsh industrial environments?
A4: Yes, it is designed for industrial use with operating temperatures from 0–60°C and 5–95% non-condensing humidity.
Q5: Is the module isolated between channels?
A5: Yes, channel-to-channel isolation is provided for enhanced safety and signal integrity.
Q6: What is the resolution of the input conversion?
A6: The card provides 16-bit resolution for precise analog measurements.
Q7: How fast is the response time for signal acquisition?
A7: The typical response time is 10 ms.
Q8: What communication interface does this card use?
A8: It interfaces through the DeltaV bus system for seamless integration with Emerson automation systems.
Q9: Does the module provide diagnostic information?
A9: Yes, it offers diagnostic feedback for easier maintenance and monitoring.
Q10: What is the power supply requirement for the card?
A10: The card requires a 24 VDC power supply.
Recommended Related or Same-Series Models
| Model Number | Description |
|---|---|
| VE4002S2B1 KJ4001X1-CA2 | Analog Input Card, 4 channels, DeltaV compatible |
| VE4004S2B1 KJ4001X1-CB1 | Analog Input Card, 8 channels, high accuracy |
| VE4005S2B1 KJ4001X1-CC1 | Analog Input Card, supports thermocouple inputs |
| VE4006S2B1 KJ4001X1-CD1 | Analog Input Card, 16-bit resolution, 4–20 mA |
| VE4007S2B1 KJ4001X1-CE1 | Analog Input Card, extended temperature range |
| VE4008S2B1 KJ4001X1-CF1 | Analog Input Card, diagnostic features enabled |
Popular Emerson Models
| Model Number | Description |
|---|---|
| KJ4001X1-BA1 | Digital Output Card, DeltaV compatible |
| KJ4001X1-BB1 | Digital Input Card, high-speed acquisition |
| KJ4002X1-CA1 | Analog Output Card, precision voltage/current |
| KJ4003X1-DA1 | Universal I/O Card, multi-signal support |
| KJ4004X1-EA1 | Safety I/O Card, SIL2 certified |
| KJ4005X1-FA1 | Temperature Input Card, thermocouple/RTD support |
