Product Introduction
The Emerson VE4003S2B9 KJ3223X1-BA1 DeltaV Analog Input Card is a high-performance module designed to handle analog signal acquisition within DeltaV distributed control systems. This card is widely used in process industries where accurate monitoring of analog signals is essential for operational reliability and efficiency.
It provides robust signal conditioning, precise conversion of field data, and seamless integration into the DeltaV platform. Its design ensures long-term stability, reliability, and compatibility with a wide range of sensors and transmitters.
Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | VE4003S2B9 KJ3223X1-BA1 |
| Product Type | DeltaV Analog Input Card |
| Input Channels | 16 isolated analog input channels |
| Signal Range | 4–20 mA, 1–5 VDC, and other configurable ranges |
| Resolution | 16-bit |
| Isolation | Channel-to-channel and channel-to-bus isolation |
| Update Rate | Configurable, high-speed acquisition |
| Communication | Integrated with DeltaV system I/O bus |
| Power Supply | 24 VDC (supplied via system backplane) |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | -40 °C to 85 °C |
| Dimensions | 107 x 41 x 105 mm |
| Weight | 0.281 kg |
Product Applications
-
Oil and gas production facilities for real-time monitoring of pressure, flow, and temperature.
-
Chemical and petrochemical plants for safe and reliable process control.
-
Power generation systems for monitoring analog variables in turbines and boilers.
-
Pharmaceutical manufacturing where precise control of environmental and process conditions is critical.
-
Water and wastewater treatment plants for continuous monitoring of pH, turbidity, and flow.
-
Pulp and paper industries for process optimization and quality assurance.
Product Advantages
-
High Accuracy: Ensures precise analog signal conversion for reliable control decisions.
-
Isolated Channels: Protects against ground loops and electrical noise, improving system reliability.
-
Seamless Integration: Fully compatible with DeltaV systems, reducing engineering effort.
-
Flexible Input Handling: Supports multiple analog ranges to accommodate diverse sensor types.
-
Robust Design: Built to withstand harsh industrial environments with long operational life.
-
Scalability: Allows easy expansion within DeltaV systems as plant requirements grow.
FAQ
Q1: How many channels does the VE4003S2B9 KJ3223X1-BA1 support?
A1: It supports 16 isolated analog input channels.
Q2: What type of isolation is provided?
A2: Each channel is isolated both from other channels and from the backplane bus.
Q3: What is the resolution of the analog input conversion?
A3: The card provides a 16-bit resolution for precise data acquisition.
Q4: Can the card handle both voltage and current inputs?
A4: Yes, it supports both 4–20 mA and 1–5 VDC input ranges, among others.
Q5: Is the update rate configurable?
A5: Yes, the acquisition speed can be configured depending on application requirements.
Q6: How does the module communicate with the DeltaV system?
A6: It communicates directly through the DeltaV I/O subsystem backplane.
Q7: What measures are in place to reduce signal noise?
A7: The card uses channel isolation and advanced filtering techniques to minimize noise.
Q8: Can this module be hot-swapped?
A8: Yes, it supports hot-swapping, reducing downtime during replacement.
Q9: Does the card require external power?
A9: No, it is powered through the DeltaV system backplane (24 VDC).
Q10: Is this card backward-compatible with older DeltaV systems?
A10: Yes, it is designed to integrate seamlessly with previous DeltaV generations.
