Product Introduction
The Emerson VE4003S6B1 DeltaV Analog Input Card is a high-performance I/O module designed to deliver accurate and reliable analog signal acquisition for DeltaV distributed control systems (DCS). It is built to handle a wide variety of process signals, ensuring seamless integration in industries such as oil & gas, chemical, power generation, and manufacturing.
With robust construction, high noise immunity, and advanced diagnostic features, the VE4003S6B1 provides exceptional performance in demanding automation environments. Its modular design allows for quick installation, replacement, and expansion, making it a preferred choice for industrial automation engineers.
Product Parameters
| Parameter | Specification |
|---|---|
| Product Model | Emerson VE4003S6B1 |
| Product Type | DeltaV Analog Input Card |
| Channels Supported | 16 Analog Input Channels |
| Signal Types Supported | 4–20 mA, 0–10 V, RTD, Thermocouple |
| Resolution | 16-bit high accuracy |
| Input Isolation | Channel-to-channel and channel-to-bus |
| Update Rate | Configurable, high-speed response |
| Diagnostic Features | Open wire detection, signal status |
| Dimensions | 107 × 41 × 105 mm |
| Weight | 0.5 kg |
| Operating Temperature | -40°C to +70°C |
| Power Supply | 24 VDC nominal |
| System Compatibility | Emerson DeltaV control systems |
Product Applications
-
Process control in chemical and petrochemical plants
-
Oil & gas upstream and downstream monitoring
-
Power generation systems (thermal, hydro, renewable)
-
Pharmaceutical and life sciences production control
-
Pulp and paper automation
-
Food and beverage manufacturing lines
Product Advantages
-
High Accuracy: 16-bit resolution ensures precise signal processing.
-
Robust Diagnostics: Built-in open circuit detection and signal validation reduce downtime.
-
Flexible Signal Handling: Supports multiple analog input types for broader application.
-
System Integration: Seamless compatibility with DeltaV DCS platform.
-
Compact and Modular Design: Easy installation, replacement, and maintenance.
-
Reliable Performance: Withstands harsh industrial conditions with extended temperature range.
FAQ
Q1: What types of analog signals can the VE4003S6B1 accept?
A1: It supports current (4–20 mA), voltage (0–10 V), RTD, and thermocouple signals.
Q2: How many channels are available on this card?
A2: The card provides 16 analog input channels.
Q3: Does the module provide input isolation?
A3: Yes, it offers channel-to-channel and channel-to-bus isolation to prevent interference.
Q4: What is the resolution of the analog inputs?
A4: The inputs provide 16-bit resolution for high accuracy.
Q5: Can the module detect open or faulty wiring?
A5: Yes, it includes diagnostic features such as open wire detection and signal status reporting.
Q6: What is the typical update rate of the module?
A6: The update rate is configurable and provides high-speed response suitable for process control.
Q7: Is it hot-swappable within the DeltaV system?
A7: Yes, the module can be replaced without shutting down the entire system.
Q8: What is the supported operating temperature range?
A8: The card operates reliably from -40°C to +70°C.
Q9: How does it integrate with the DeltaV system?
A9: It plugs directly into the DeltaV I/O subsystem and communicates seamlessly with the controller.
Q10: What diagnostic feedback can it provide to operators?
A10: It reports signal quality, open wiring, and fault conditions to the system for quick troubleshooting.
