Product Overview
The Emerson VE4003S6B1 KJ3225X1-BA1 Analog Input Card is a high-performance input module engineered for use within Emerson DeltaV control systems. It provides precise acquisition and conversion of analog signals such as temperature, pressure, flow, and level, ensuring accurate monitoring and control of critical process variables. With multi-channel support, built-in isolation, and hot-swappable capability, this module delivers robust performance and reliability in demanding industrial environments.
Key Features
-
High-accuracy analog input processing for DeltaV systems
-
Supports multiple signal types including 4–20 mA and voltage inputs
-
16-channel configuration for efficient signal integration
-
Hot-swappable design enables replacement without system downtime
-
Advanced diagnostics for fault detection and troubleshooting
-
Channel-to-channel and system isolation for enhanced safety
-
Compact DIN-rail compatible form factor
Technical Specifications
| Item | Specification |
|---|---|
| Manufacturer | Emerson |
| Model | VE4003S6B1 / KJ3225X1-BA1 |
| Product Type | Analog Input Card |
| Number of Channels | 16 |
| Input Type | Current (4–20 mA) and Voltage |
| Accuracy | ±0.1% of full scale |
| Response Time | < 10 ms |
| Isolation | Channel-to-channel and channel-to-system |
| Supply Voltage | 24 VDC |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Humidity | 5–95% RH (non-condensing) |
| Dimensions | 107 x 41 x 105 mm |
| Weight | 0.5 kg |
| Applications | Process variable monitoring in industrial automation |
Industry Applications
-
Oil & Gas process automation
-
Power generation systems
-
Chemical and petrochemical industries
-
Pharmaceutical production and quality control
-
Water and wastewater treatment plants
-
Pulp and paper process monitoring
-
General industrial automation
Frequently Asked Questions (FAQ)
Q1: What is the function of the VE4003S6B1 Analog Input Card?
It measures analog process variables like temperature, flow, pressure, and level.
Q2: How many channels does this card support?
It supports 16 analog input channels.
Q3: What type of signals are supported?
It supports current (4–20 mA) and voltage signals.
Q4: Is the module hot-swappable?
Yes, it can be replaced without shutting down the system.
Q5: What is the accuracy of measurement?
It provides an accuracy of ±0.1% of full scale.
Q6: What is the operating temperature range?
It operates between 0 °C and +60 °C.
Q7: Is it compatible with Emerson DeltaV systems?
Yes, it is designed specifically for DeltaV I/O integration.
Q8: What are the module’s dimensions and weight?
Dimensions: 107 x 41 x 105 mm, Weight: 0.5 kg.
