Product Introduction
The Emerson VE4005S2B5 Analog Output Card is a high-performance module designed for DeltaV distributed control systems. It provides reliable analog output signals for precise control of field devices such as actuators, control valves, and other instrumentation requiring current or voltage signals. This card ensures smooth process regulation and integrates seamlessly into the Emerson DeltaV system architecture, enabling robust control in demanding industrial environments.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Type | Analog Output Card |
| Model Number | VE4005S2B5 |
| Channels | 8 independent analog output channels |
| Output Signal Types | 4–20 mA, 0–20 mA, configurable voltage |
| Resolution | 12-bit digital-to-analog conversion |
| Accuracy | ±0.1% of full scale |
| Isolation | Channel-to-bus and channel-to-channel isolation |
| Power Supply | 24 V DC (redundant supply supported) |
| Diagnostics | Built-in self-test and fault detection |
| Operating Temperature | -40 °C to +70 °C |
| Storage Temperature | -40 °C to +85 °C |
| Dimensions | 107 x 41 x 105 mm |
| Weight | 0.281 kg |
Product Applications
-
Process Control: Driving control valves, positioners, and final control elements.
-
Power Generation: Managing turbine actuators and regulating excitation systems.
-
Oil & Gas: Controlling flow and pressure regulation equipment.
-
Pharmaceuticals: Ensuring precision in batch processing and laboratory automation.
-
Chemical Industry: Outputting stable signals for reactors, pumps, and mixers.
-
Water & Wastewater: Regulating pumps, motors, and treatment plant actuators.
Product Advantages
-
High Reliability: Engineered for mission-critical process environments with fault-tolerant design.
-
Flexible Output Configuration: Supports both current and voltage analog signals.
-
Advanced Diagnostics: Provides status monitoring and error detection to reduce downtime.
-
Seamless Integration: Fully compatible with DeltaV control systems for plug-and-play setup.
-
Isolation Protection: Ensures safety by minimizing interference between channels.
-
Compact Design: Saves space in control cabinets while maintaining high output performance.
FAQ
Q1: How many analog output channels does the VE4005S2B5 provide?
A1: It provides 8 independent analog output channels.
Q2: What types of signals can this card output?
A2: It can output 4–20 mA, 0–20 mA, and configurable voltage signals.
Q3: Does the card support redundant power supply connections?
A3: Yes, it supports redundant 24 V DC supply to ensure uninterrupted operation.
Q4: What is the resolution of the digital-to-analog conversion?
A4: The resolution is 12-bit, enabling precise signal generation.
Q5: Is channel isolation supported on this module?
A5: Yes, it provides both channel-to-bus and channel-to-channel isolation.
Q6: What diagnostic features are included?
A6: The card has built-in self-tests, fault detection, and signal verification.
Q7: Can this module operate in extreme industrial environments?
A7: Yes, it is rated for -40 °C to +70 °C, suitable for harsh conditions.
Q8: How does this card integrate with DeltaV systems?
A8: It is fully plug-and-play compatible with DeltaV controllers and I/O subsystems.
Q9: What is the accuracy of analog outputs?
A9: The card maintains ±0.1% of full-scale accuracy.
Q10: Can the card drive high-demand control valves directly?
A10: Yes, it can directly drive control valves and actuators requiring analog current or voltage signals.
