Emerson VE4033S2B1 KJ3222X1-BA1 DeltaV Analog Input Card
The Emerson VE4033S2B1 KJ3222X1-BA1 is an analog input module designed for DeltaV DCS systems. It provides high-performance analog signal acquisition and integrates seamlessly into process control environments. Its compact size and reliability make it suitable for a wide range of industrial applications.
Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | VE4033S2B1 / KJ3222X1-BA1 |
| Signal Type | Analog Input |
| Channels | 8 isolated channels |
| Input Range | 0–10 V, 4–20 mA |
| Resolution | 16-bit |
| Isolation | Channel-to-channel and system |
| Update Rate | 250 ms (typical) |
| Power Supply | 24 VDC |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions | 107 x 41 x 105 mm |
| Weight | 0.18 kg |
Applications
The VE4033S2B1 is widely used in:
-
Chemical and petrochemical plants
-
Oil and gas refineries
-
Water and wastewater treatment systems
-
Power generation facilities
-
Pulp and paper industries
-
Food and beverage processing
Advantages
-
High accuracy and fast response for critical process monitoring
-
Excellent isolation to prevent interference between channels
-
Compatible with DeltaV architecture for plug-and-play integration
-
Rugged design suitable for harsh industrial conditions
-
Compact form factor saves cabinet space
-
Supports various input types with configurable ranges
FAQ
Q1: What types of analog signals does the VE4033S2B1 support?
A1: It supports voltage (0–10 V) and current (4–20 mA) inputs.
Q2: How many channels are available on this module?
A2: The module offers 8 isolated analog input channels.
Q3: Is the module hot-swappable?
A3: Yes, it can be replaced while the system is powered without interrupting operations.
Q4: What is the resolution of the input signal?
A4: The module features a 16-bit resolution for accurate signal measurement.
Q5: Is the VE4033S2B1 compatible with all DeltaV systems?
A5: Yes, it is fully compatible with Emerson DeltaV DCS systems.
Q6: Can this module operate in extreme temperature environments?
A6: Yes, it operates in temperatures ranging from -40°C to +70°C.
Q7: How is isolation implemented in this module?
A7: Each channel is isolated from others and from the system to reduce noise and crosstalk.
Q8: What is the typical update rate for the analog signals?
A8: The typical update rate is 250 milliseconds.
Q9: Is configuration done via hardware or software?
A9: Configuration is done via DeltaV software for ease and flexibility.
Q10: What is the installation orientation for this module?
A10: It is designed for standard vertical mounting in DeltaV enclosures.
Related or Similar Models
| Model Number | Channels | Signal Type | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| VE4034S2B1 | 8 | Analog Output | 107 x 41 x 105 | 0.18 |
| VE4035S2B1 | 16 | DI | 107 x 41 x 105 | 0.19 |
| VE4036S2B1 | 16 | DO | 107 x 41 x 105 | 0.19 |
| VE4037S2B1 | 8 | RTD Input | 107 x 41 x 105 | 0.18 |
| KJ3002X1-BG1 | 4 | AI | 107 x 41 x 105 | 0.18 |
| KJ3001X1-BA1 | 4 | AO | 107 x 41 x 105 | 0.18 |
Popular Emerson Models
| Model Number | Function | Dimensions (mm) | Weight (kg) |
|---|---|---|---|
| KJ3001X1-BB1 | Analog Output | 107 x 41 x 105 | 0.18 |
| KJ3002X1-BG2 | Analog Input | 107 x 41 x 105 | 0.18 |
| KJ4001X1-NA1 | CPU Controller | 160 x 70 x 105 | 0.30 |
| KJ4010X1-BA2 | Power Supply | 160 x 70 x 105 | 0.45 |
| KJ3241X1-BA1 | RTD Input | 107 x 41 x 105 | 0.18 |
| KJ3221X1-BA1 | Thermocouple AI | 107 x 41 x 105 | 0.18 |
