Product Introduction
The Epro PR6423/00R-010-CN+CON021 is a high-precision 8mm eddy current sensor designed for displacement, position, and vibration measurement in industrial automation, process control, and machinery monitoring systems. This sensor utilizes the principle of eddy current measurement to detect the distance between the sensor and a conductive target without any physical contact, making it ideal for non-contact measurement applications in a wide range of industrial environments.
With a sensor head diameter of 8 mm, the PR6423/00R-010-CN+CON021 provides high accuracy and sensitivity while maintaining a compact form factor. This sensor is particularly suitable for detecting small displacements in machine parts, shafts, or other moving components, where traditional contact-based methods might be prone to wear or damage.
The Epro PR6423/00R-010-CN+CON021 sensor is designed to meet the stringent requirements of industries such as automotive manufacturing, aerospace, and rotating machinery diagnostics. It features easy integration with other control and measurement systems, making it a versatile solution for a variety of applications where precision and reliability are critical.
Product Parameters
The following are the key technical specifications for the Epro PR6423/00R-010-CN+CON021 8mm eddy current sensor:
| Parameter | Specification |
|---|---|
| Model Number | PR6423/00R-010-CN+CON021 |
| Sensor Type | Eddy Current Displacement Sensor |
| Sensor Head Diameter | 8 mm |
| Weight | 0.22 kg |
| Measurement Range | ±2 mm |
| Output Type | Analog (Voltage / Current) |
| Supply Voltage | 10 V to 30 V DC |
| Signal Output | 0-10 V, 4-20 mA |
| Frequency Response | 1 kHz (max) |
| Operating Temperature Range | -20°C to +80°C |
| Mounting Type | Threaded, Adjustable Mounting Bracket |
| Compliance | CE, RoHS |
Product Applications
The Epro PR6423/00R-010-CN+CON021 sensor is commonly used for precise measurements in applications requiring non-contact displacement and position sensing. Some key areas of use include:
-
Rotating Machinery Monitoring: The sensor is ideal for detecting small displacements in rotating machinery, including motors, gearboxes, and pumps, ensuring the early detection of potential mechanical issues such as misalignment or vibration.
-
Automotive Manufacturing: In the automotive industry, the sensor is used to monitor components in engine assembly lines, chassis manufacturing, and other critical systems, providing real-time data for quality control and performance testing.
-
Aerospace Applications: The PR6423/00R-010-CN+CON021 is used in aerospace for precise measurement of turbine blades, jet engine components, and other critical parts where accuracy is crucial for safety and reliability.
-
High-Precision Positioning: The sensor is often employed in precision assembly systems for applications where precise position control is required, such as in robotics and automation systems.
-
Vibration Measurement: The sensor’s ability to detect tiny displacements makes it an excellent choice for monitoring vibrations in industrial machinery, helping to identify potential failure points early in the process.
-
Material Testing: In material testing setups, it provides accurate feedback on the displacement of materials during stress tests, helping engineers to assess material properties in real-time.
Product Advantages
-
Non-Contact Measurement: The PR6423/00R-010-CN+CON021 sensor operates on the principle of eddy current technology, providing accurate measurements without physical contact with the target, thereby eliminating wear and tear associated with traditional contact-based sensors.
-
Compact and Precise: With an 8 mm sensor head diameter, the sensor offers high precision in a compact form factor, making it ideal for applications in constrained spaces or where high accuracy is needed.
-
Wide Temperature Range: The sensor operates effectively across a wide temperature range of -20°C to +80°C, making it suitable for use in a variety of industrial environments.
-
High Frequency Response: With a frequency response of 1 kHz, the sensor can track fast-moving targets and provide real-time data for dynamic systems, ensuring high-speed performance.
-
Easy Integration: The PR6423/00R-010-CN+CON021 sensor features an analog output that is compatible with most control and measurement systems, allowing for easy integration into existing setups.
-
Durability and Reliability: Built to withstand harsh industrial environments, the sensor is durable and offers long-term reliability with minimal maintenance requirements.
-
Versatile Application: The sensor can be used in a wide range of industries, including automotive, aerospace, and manufacturing, for a variety of displacement and vibration monitoring tasks.
-
Signal Output Flexibility: It offers both voltage (0-10 V) and current (4-20 mA) output options, providing flexibility for different system requirements.
-
Cost-Effective Solution: With its high precision and durability, the PR6423/00R-010-CN+CON021 offers a cost-effective solution for non-contact measurement applications, reducing the need for expensive and maintenance-intensive contact sensors.
-
High Sensitivity: Capable of measuring tiny displacements, the sensor provides highly sensitive data that can be used for detecting early signs of mechanical failure in critical systems.
FAQ
1. What is the working principle of the Epro PR6423/00R-010-CN+CON021?
The Epro PR6423/00R-010-CN+CON021 uses eddy current technology to measure displacement or position of a conductive target without physical contact. This ensures accurate, non-contact measurements, ideal for dynamic and high-precision applications.
2. What is the measurement range of the PR6423/00R-010-CN+CON021?
The PR6423/00R-010-CN+CON021 has a measurement range of ±2 mm, making it suitable for detecting small displacements in industrial machinery and components.
3. How does the sensor output data?
The PR6423/00R-010-CN+CON021 provides an analog output, available in both 0-10 V and 4-20 mA, offering flexibility for integration into different systems.
4. Can the PR6423/00R-010-CN+CON021 be used in high-speed applications?
Yes, with a frequency response of 1 kHz, the PR6423/00R-010-CN+CON021 is suitable for high-speed measurements in dynamic systems like rotating machinery and automotive testing.
5. What is the operating temperature range of the sensor?
The sensor operates effectively in environments with temperatures ranging from -20°C to +80°C, making it suitable for a wide range of industrial environments.
6. How is the PR6423/00R-010-CN+CON021 mounted?
The sensor features a threaded mounting type with an adjustable mounting bracket, ensuring easy installation and secure positioning.
7. What industries use the PR6423/00R-010-CN+CON021?
The sensor is commonly used in automotive manufacturing, aerospace, industrial automation, vibration monitoring, and material testing applications.
8. Can the PR6423/00R-010-CN+CON021 be used in harsh environments?
Yes, the sensor is designed for use in harsh industrial environments and is durable enough to withstand challenging operating conditions.
9. What types of targets can the PR6423/00R-010-CN+CON021 sensor detect?
The sensor can detect conductive targets, making it suitable for use in applications involving metallic parts, components, or machinery.
10. Is the PR6423/00R-010-CN+CON021 compatible with existing control systems?
Yes, the PR6423/00R-010-CN+CON021 sensor offers analog outputs (0-10 V or 4-20 mA), making it compatible with most industrial control and measurement systems.
