Product Introduction
The Epro PR6423/010-000-CN is a high-precision 8mm eddy current sensor, designed for non-contact displacement measurement in a variety of industrial applications. Using the principle of eddy current technology, this sensor detects the displacement or proximity of conductive targets without physical contact, making it ideal for dynamic environments where traditional mechanical sensors would fail due to wear, friction, or the harsh conditions of the system.
This sensor is particularly useful for applications that require high-frequency response and extreme precision, such as vibration monitoring, positioning systems, and rotating machinery. With its 8mm sensor head, the PR6423/010-000-CN offers a compact solution without compromising measurement quality. Whether used in robotics, automated manufacturing, or aerospace, the sensor ensures reliable performance and long-term stability.
The PR6423/010-000-CN also features an analog output and is easy to integrate with industrial control systems, allowing real-time data acquisition and system optimization. Its versatility makes it suitable for a broad range of industries, including automotive, energy, aerospace, and industrial automation.
Product Parameters
The key specifications for the Epro PR6423/010-000-CN 8mm eddy current sensor are as follows:
| Parameter | Specification |
|---|---|
| Model Number | PR6423/010-000-CN |
| Sensor Type | Eddy Current Displacement Sensor |
| Sensor Head Diameter | 8 mm |
| Weight | 0.1 kg |
| Measurement Range | ±2 mm |
| Output Type | Analog (0-10 V, 4-20 mA) |
| Supply Voltage | 10 V to 30 V DC |
| Frequency Response | 1 kHz (Max) |
| Operating Temperature Range | -20°C to +80°C |
| Mounting Type | Threaded, Adjustable Mounting Bracket |
| Compliance | CE, RoHS |
Product Applications
The Epro PR6423/010-000-CN sensor is suitable for a wide range of applications, particularly in industries requiring non-contact displacement and position sensing. The following are some typical use cases:
-
Rotating Machinery Monitoring: The PR6423/010-000-CN excels in monitoring vibration and displacement in motors, turbines, and rotating machinery, ensuring operational efficiency and preventing equipment failure.
-
Aerospace: The sensor is widely used in the aerospace sector for positioning and vibration monitoring of critical components like turbine blades and engine parts.
-
Automotive Industry: It is an essential component for robotics and automated assembly lines, where precision measurements of displacement or alignment are required.
-
Industrial Automation: This sensor is ideal for applications involving motion control and process automation, where high accuracy and responsiveness are essential for production optimization.
-
Material Testing and R&D: The PR6423/010-000-CN is used in research and development labs for stress testing and material analysis, ensuring precise readings for various material properties.
-
Vibration and Condition Monitoring: It is widely applied in industries where constant monitoring of machinery health is necessary to detect misalignment, vibrations, or other anomalies.
Product Advantages
-
Non-Contact Measurement: The PR6423/010-000-CN uses eddy current technology, which means it does not require physical contact with the target, resulting in minimal wear and long-term durability.
-
High Precision: With a measurement range of ±2 mm, the sensor provides high-accuracy measurements, making it suitable for demanding applications where precision is critical.
-
Compact Design: The 8mm sensor head is compact, making the sensor ideal for tight spaces or applications with limited mounting room, without sacrificing accuracy.
-
Fast Response Time: With a frequency response of 1 kHz, the sensor can accurately measure high-speed movements or rapid changes in position or vibration.
-
Wide Temperature Range: It operates in extreme environmental conditions, with a temperature range of -20°C to +80°C, ensuring performance in challenging industrial environments.
-
Flexible Output Options: The sensor provides 0-10 V or 4-20 mA output, offering compatibility with most industrial measurement systems.
-
Durability: The rugged design ensures the sensor can withstand the stresses of high-vibration environments, electromagnetic interference, and harsh operating conditions.
-
Easy Integration: With its analog output and flexible mounting options, the sensor is easy to integrate into existing systems for real-time measurement and control.
-
Low Maintenance: The non-contact nature of the sensor means reduced wear and tear, leading to fewer maintenance requirements and longer lifespan.
-
Cost-Effective Solution: Given its high performance and durability, the PR6423/010-000-CN is a cost-effective solution for industries needing accurate displacement and vibration measurements.
FAQ
1. How does the Epro PR6423/010-000-CN sensor work?
The PR6423/010-000-CN uses eddy current technology, generating an electromagnetic field that detects the displacement of conductive targets without making physical contact.
2. What is the output signal provided by the PR6423/010-000-CN sensor?
The sensor provides analog output signals of 0-10 V or 4-20 mA, suitable for integration with various industrial control and monitoring systems.
3. What is the measurement range of the PR6423/010-000-CN sensor?
The PR6423/010-000-CN has a measurement range of ±2 mm, allowing for precise displacement measurement in both static and dynamic conditions.
4. What is the frequency response of the sensor?
The PR6423/010-000-CN sensor offers a 1 kHz frequency response, making it ideal for applications that require real-time measurement of fast-moving targets.
5. Can the PR6423/010-000-CN sensor measure non-metallic targets?
No, the PR6423/010-000-CN sensor is designed to measure conductive targets only, such as metals and alloys, and does not work with non-metallic materials.
6. What are the operating temperature ranges for this sensor?
The sensor operates within a temperature range of -20°C to +80°C, allowing it to function reliably in various industrial environments.
7. Is the PR6423/010-000-CN suitable for use in vibration monitoring?
Yes, the PR6423/010-000-CN is well-suited for vibration monitoring in rotating machinery, providing accurate displacement measurements for condition monitoring.
8. What mounting options are available for the PR6423/010-000-CN sensor?
The sensor features a threaded mounting design with an adjustable bracket, making installation easy and flexible in various industrial setups.
9. How does the sensor provide displacement measurements?
The sensor measures the change in the eddy current field caused by the displacement of a conductive target. This change is translated into a corresponding voltage or current output signal.
10. Can the PR6423/010-000-CN sensor be used for high-speed applications?
Yes, with its high-frequency response (up to 1 kHz), the sensor can accurately measure fast-moving or vibrating targets, making it suitable for high-speed applications.
