Product Introduction
The Epro PR6424/010-130 16mm Eddy Current Sensor is a high-precision displacement sensor designed to measure the distance between a sensor and a metallic target. Utilizing the principle of eddy current technology, this sensor provides accurate and reliable measurements in demanding industrial environments. The sensor is built for continuous operation and offers exceptional resistance to high temperature and harsh conditions. The 16mm sensing range is ideal for applications where precision and stability are critical, such as in machine monitoring, vibration analysis, and high-speed rotating machinery.
The Epro PR6424/010-130 is commonly used in applications that require non-contact measurement of displacement, such as rotor position monitoring in turbines, pump alignment, and sensor feedback in high-performance motors. Its compact design and advanced technology make it a go-to solution for systems that require consistent performance in extreme environments.
Product Specifications
| Parameter | Specification |
|---|---|
| Model | Epro PR6424/010-130 16mm Eddy Current Sensor |
| Measurement Principle | Eddy Current Displacement Measurement |
| Sensor Head Diameter | 16 mm |
| Measuring Range | ±8 mm (from the sensor’s central position) |
| Output Type | Analog (4-20 mA or 0-10 V) |
| Output Frequency | Up to 20 kHz (depending on application) |
| Linearity | ±0.1% (over full measurement range) |
| Resolution | 0.01 mm |
| Sensor Type | Non-contact, proximity sensor |
| Sensor Head Material | Stainless Steel (for high durability) |
| Housing Material | Aluminum or Stainless Steel (depending on variant) |
| Operating Temperature | -20°C to +85°C (up to +150°C with special versions) |
| Storage Temperature | -40°C to +100°C |
| Response Time | Typically 1 ms |
| Weight | 0.32 kg |
| Power Supply | 24 VDC ±10% (standard); options for different configurations |
| Protection Rating | IP67 (dust and water resistant) |
| Connection Type | M12 Connector (for ease of integration) |
| Mounting | Threaded mounting (M10 or M12) for easy installation |
| Signal Processing | Internal signal processing for improved accuracy and noise rejection |
Product Applications
The Epro PR6424/010-130 16mm Eddy Current Sensor is designed for a broad range of industrial applications where non-contact displacement or position measurement is required. These include:
-
Vibration Monitoring: Used in machinery like turbines, pumps, and motors to monitor vibration levels, ensuring that machinery operates within safe tolerances.
-
Rotational Speed and Position Feedback: Ideal for monitoring rotor positions in rotating machinery or gearboxes, ensuring precise alignment and performance.
-
Alignment and Displacement Measurement: Used in precision alignment tasks in high-speed machines such as turbines, compressors, and generators.
-
Proximity Measurement: In harsh environments, where contact-based sensors may fail due to high temperatures or wear, this non-contact sensor provides accurate measurements.
-
Quality Control in Manufacturing: Used for continuous measurement of critical parts during production to detect any dimensional deviations.
-
Robotic Systems: Integrated into robotics for precise distance measurements and positioning feedback.
Product Advantages
-
High Precision and Resolution: Provides highly accurate measurements with a resolution of 0.01 mm, making it ideal for applications that require precise displacement data.
-
Non-contact Measurement: Being a non-contact sensor, it eliminates wear and tear associated with physical contact, thus extending the lifespan of both the sensor and the equipment.
-
Wide Operating Temperature Range: With an operational range from -20°C to +85°C, and the ability to withstand even higher temperatures in special versions, this sensor is suitable for harsh industrial environments.
-
Fast Response Time: With a typical response time of 1 ms, the sensor provides real-time displacement feedback, crucial for high-speed monitoring and control applications.
-
Durability and Reliability: Constructed with high-quality materials like stainless steel for the sensor head and aluminum for the housing, the sensor is built to last in demanding conditions.
-
Compact and Easy Integration: The 16mm sensing head allows for easy integration into space-constrained environments while maintaining accurate measurements.
-
High Protection Rating: With an IP67 rating, the sensor is protected against dust and water ingress, ensuring reliability in a variety of environmental conditions.
-
Versatile Output Options: The sensor offers both analog output (4-20 mA or 0-10 V), making it adaptable for various control systems and monitoring platforms.
Frequently Asked Questions (FAQ)
-
What is the maximum measurement range of the Epro PR6424/010-130 sensor?
The sensing range is 16 mm, with a measurement range of ±8 mm from the center position. -
Can the sensor be used in high-temperature environments?
Yes, the sensor can operate in temperatures up to +85°C, and versions for higher temperatures are also available. -
What is the output type of the Epro PR6424/010-130 sensor?
The sensor provides an analog output, available in either 4-20 mA or 0-10 V configurations. -
How do I mount the sensor?
The sensor can be easily mounted using a threaded connection (M10 or M12). -
What is the resolution of the sensor?
The resolution is 0.01 mm, ensuring very fine and accurate measurements. -
Is the sensor suitable for use in industrial automation systems?
Yes, the sensor is ideal for industrial automation applications, providing precise displacement measurements for real-time control. -
What materials are used in the construction of the sensor?
The sensor head is made from stainless steel for durability, while the housing is typically aluminum or stainless steel. -
How is the sensor connected to control systems?
The sensor is equipped with an M12 connector for easy integration with automation and control systems. -
What is the protection rating of the Epro PR6424/010-130 sensor?
It has an IP67 rating, providing protection against dust and water. -
Can the sensor be used for vibration monitoring in rotating machinery?
Yes, the Epro PR6424/010-130 sensor is ideal for monitoring vibrations and rotor position in rotating machinery.
Related Models (Same Series / Similar Functionality)
| Model Number | Description |
|---|---|
| Epro PR6424/010-120 | 16mm Eddy Current Sensor, 0-5 mm range, Analog output |
| Epro PR6424/010-140 | 16mm Eddy Current Sensor, 0-10 mm range, Analog output |
| Epro PR6424/010-135 | 16mm Eddy Current Sensor, Extended range, Higher precision |
| Epro PR6424/010-110 | 16mm Eddy Current Sensor, Smaller footprint, Higher frequency output |
| Epro PR6424/010-125 | 16mm Eddy Current Sensor, Longer measurement range |
| Epro PR6424/010-150 | 16mm Eddy Current Sensor, Dual output type (Analog and Digital) |
Popular Epro Models (Same Brand)
| Model Number | Description |
|---|---|
| Epro PR6423/000-010 | High-precision proximity sensor for non-contact measurement |
| Epro PR6423/001-020 | Displacement sensor, 10mm range, high-frequency output |
| Epro PR6422/010-200 | 8mm Eddy Current sensor with advanced signal processing |
| Epro PR6420/010-400 | High-sensitivity eddy current sensor for fine measurements |
| Epro PR6424/000-050 | Dual output Eddy Current Sensor, for critical applications |
| Epro PR6400/002-030 | Multi-range eddy current sensor for versatile applications |
