Product Introduction
The Epro PR6424/01CS 16mm Eddy Current Sensor is a precision measurement tool designed to provide non-contact displacement and proximity measurements in industrial applications. Based on the principle of eddy currents, this sensor is highly accurate, stable, and capable of measuring small displacements with minimal drift over time. The 16mm model offers exceptional resolution and response speed, making it suitable for demanding applications such as rotor blade measurement, bearing analysis, and vibration monitoring.
With its rugged design, the PR6424/01CS is built to withstand harsh industrial environments, offering reliable and continuous performance. The sensor is ideal for both dynamic and static measurements, ensuring high accuracy even in fluctuating or high-temperature conditions. Its compact design allows for easy integration into control and monitoring systems, offering seamless functionality for process control and predictive maintenance applications.
Product Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Epro |
| Model Number | PR6424/01CS |
| Type | Eddy Current Sensor |
| Measuring Range | 16 mm (range of displacement) |
| Output Signal | Analog (4-20 mA) |
| Sensor Technology | Eddy Current |
| Resolution | 0.01 mm |
| Frequency Response | Up to 100 kHz |
| Operating Temperature | -40°C to +150°C |
| Storage Temperature | -40°C to +85°C |
| Accuracy | ±0.1% of full scale |
| Weight | 0.2 kg |
| Cable Length | 3 meters (standard) |
| Housing Material | Stainless Steel |
| Protection Rating | IP65 (Dust-tight and water-resistant) |
| Electrical Connection | M12, 5-pin connector |
| Supply Voltage | 24 VDC |
| Calibration Type | Factory calibrated |
Product Applications
The Epro PR6424/01CS 16mm Eddy Current Sensor is designed for a broad range of industrial applications where precision and reliability are crucial. Some of the key applications include:
-
Rotating Machinery Monitoring: Ideal for measuring shaft displacement, vibration, and rotor blade position in rotating equipment.
-
Condition Monitoring: Used for monitoring the health of motors, turbines, and compressors by detecting minute shifts in position or vibration.
-
Proximity Sensing: Suitable for non-contact measurement of proximity in applications such as distance sensing in automotive and manufacturing processes.
-
Bearing Condition Monitoring: Measures bearing wear or misalignment, providing early detection of faults before failure occurs.
-
Vibration Analysis: Ensures accurate measurement of mechanical vibrations in machines, which is critical for predictive maintenance and fault diagnostics.
-
Non-contact Measurement in Harsh Environments: Performs in extreme temperatures and high-vibration environments, making it ideal for use in aerospace, power generation, and mining industries.
Product Advantages
-
Non-contact Measurement: The sensor operates without physical contact, eliminating the risk of wear and reducing maintenance requirements.
-
High Accuracy: With a resolution of 0.01 mm and an accuracy of ±0.1%, the PR6424/01CS provides precise measurements, even for small displacements.
-
Wide Operating Temperature Range: The sensor performs effectively across a broad temperature range, from -40°C to +150°C, making it suitable for use in harsh industrial conditions.
-
Durable Design: Encased in a stainless-steel housing with an IP65 protection rating, the sensor is resistant to dust, moisture, and mechanical impact.
-
Fast Response Time: With a frequency response of up to 100 kHz, the sensor can capture rapid displacements and provide real-time data for high-speed applications.
-
Long-Term Stability: The PR6424/01CS sensor exhibits minimal drift over time, ensuring reliable measurements for long periods.
-
Ease of Integration: It features an M12, 5-pin connector, making it easy to integrate into existing monitoring and control systems.
-
Compact Design: The 16mm measurement range and compact form factor make it easy to incorporate into tight spaces without compromising performance.
-
Versatility: Capable of measuring both dynamic and static displacements, the sensor can be used in a wide range of applications, from condition monitoring to automation.
-
Factory Calibration: The sensor is factory-calibrated, ensuring high accuracy right out of the box, with minimal need for user intervention.
Frequently Asked Questions (FAQ)
-
What is the measuring range of the Epro PR6424/01CS 16mm Eddy Current Sensor?
The measuring range is 16 mm, suitable for detecting small displacements and proximity. -
What output signal does the sensor provide?
The sensor provides an analog output signal of 4-20 mA. -
What is the resolution of the PR6424/01CS sensor?
The sensor has a resolution of 0.01 mm, allowing it to detect fine displacements. -
Can the sensor be used in high-temperature environments?
Yes, the PR6424/01CS operates within a temperature range of -40°C to +150°C, making it suitable for high-temperature applications. -
How accurate is the PR6424/01CS?
The sensor offers an accuracy of ±0.1% of full scale. -
What is the protection rating of the sensor?
The sensor has an IP65 protection rating, meaning it is dust-tight and resistant to water jets. -
What type of connector is used for electrical connections?
The sensor uses a standard M12, 5-pin connector for easy electrical connection. -
What material is the sensor housing made of?
The sensor housing is made of durable stainless steel, ensuring robustness in industrial environments. -
What industries can benefit from using this sensor?
Industries such as aerospace, power generation, mining, and manufacturing can all benefit from using the PR6424/01CS for condition monitoring and displacement measurements. -
Is the sensor factory calibrated?
Yes, the PR6424/01CS comes factory calibrated, ensuring accurate and reliable performance right from installation.
Related Models from the Same Series or System
| Model Number | Description | Measuring Range | Accuracy |
|---|---|---|---|
| PR6424/02CS | 25mm Eddy Current Sensor | 25 mm | ±0.1% |
| PR6424/03CS | 50mm Eddy Current Sensor | 50 mm | ±0.1% |
| PR6424/04CS | 100mm Eddy Current Sensor | 100 mm | ±0.1% |
| PR6424/01SS | Stainless Steel Housing Eddy Current Sensor | 16 mm | ±0.1% |
| PR6424/01HR | High Resolution Eddy Current Sensor | 16 mm | ±0.05% |
| PR6424/01TR | Temperature Resistant Eddy Current Sensor | 16 mm | ±0.1% |
