Product Introduction
The Epro PR6424/104-000 is a 16mm Eddy Current Sensor designed for high-precision measurement in industrial applications. Eddy current sensors are widely used for non-contact measurement of displacement, distance, position, and vibration of conductive materials. These sensors operate based on the principle of eddy current interaction between a sensor probe and the target material. The PR6424/104-000 model offers superior accuracy, fast response time, and reliable performance in challenging environments.
This sensor is ideal for applications that require non-contact sensing of small displacements or vibrations with high precision. It is commonly used in applications where traditional contact sensors would be unsuitable due to wear, contamination, or other challenges. The 16mm diameter of the sensor head makes it suitable for compact installations, while its rugged construction ensures reliable operation in industrial settings.
Product Specifications
| Feature | Details |
|---|---|
| Sensor Head Diameter | 16 mm |
| Weight | 0.2 kg |
| Measuring Range | Up to 10 mm |
| Output Type | Analog Output (4-20mA, 0-10V) |
| Frequency Range | Up to 100 kHz |
| Operating Voltage | 24V DC |
| Accuracy | ± 0.1% of Full Scale |
| Response Time | < 1 ms |
| Material | Stainless Steel |
| Temperature Range | -20°C to +85°C |
| Environmental Rating | IP67 |
| Mounting Type | Threaded mounting, adjustable |
Product Applications
The Epro PR6424/104-000 16mm Eddy Current Sensor is designed for a variety of industrial and engineering applications where precise, non-contact measurement is required. Key applications include:
-
Vibration Monitoring
Used in machinery, turbines, and engines to monitor vibration levels and detect imbalances, wear, or damage in rotating equipment. -
Displacement and Position Sensing
Ideal for measuring small displacements in automotive, aerospace, and manufacturing systems, where traditional contact methods may fail due to wear or contamination. -
Thickness Measurement
In industries like metals or plastics, the sensor can be used to measure the thickness of materials without contact, reducing risk of damage to delicate surfaces. -
Proximity Sensing
The sensor can detect the position of metal objects in assembly lines, automation processes, and quality control applications. -
Turbine Blade and Rotor Monitoring
In the energy sector, this sensor is used to monitor the position and vibration of turbine blades and rotors, ensuring proper operation and safety. -
Non-Contact Wear Detection
For industrial machinery and equipment, it helps in detecting wear without needing direct contact, thus preventing damage to parts and reducing maintenance downtime.
Product Advantages
-
High Accuracy and Precision
The PR6424/104-000 provides exceptional accuracy of ±0.1% of full scale, ensuring precise measurements even in critical applications. -
Non-Contact Measurement
The sensor’s eddy current principle allows for non-contact measurement, preventing wear, contamination, and physical damage to the target surface. -
Fast Response Time
With a response time of less than 1 ms, this sensor is ideal for high-speed applications where real-time data is crucial for system performance. -
Compact and Lightweight
The 16mm diameter of the sensor head and a weight of only 0.2 kg make it suitable for installations in tight spaces where traditional sensors might not fit. -
Rugged Design
With an IP67 environmental rating, the sensor is resistant to dust and water, making it highly durable and reliable in harsh industrial environments. -
Wide Temperature Range
The temperature range of -20°C to +85°C allows the sensor to operate in a wide variety of industrial settings, including extreme temperature environments.
FAQ
-
What is the maximum measuring range of the Epro PR6424/104-000 Eddy Current Sensor?
The PR6424/104-000 has a maximum measuring range of up to 10 mm, making it suitable for measuring small displacements. -
What output types are available for the PR6424/104-000 sensor?
The sensor provides analog outputs, including 4-20mA and 0-10V options for easy integration into control systems. -
What is the accuracy of the PR6424/104-000 sensor?
The sensor offers an accuracy of ±0.1% of full scale, providing precise measurements for demanding applications. -
What is the response time of the Epro PR6424/104-000 sensor?
The response time of the sensor is less than 1 ms, ensuring it can quickly capture dynamic changes in the measured system. -
What material is the sensor head made of?
The sensor head is made of stainless steel, which provides durability and resistance to corrosion in industrial environments. -
What is the environmental rating of the Epro PR6424/104-000 sensor?
The sensor has an IP67 environmental rating, meaning it is dust-tight and resistant to water immersion, making it suitable for harsh environments. -
What is the operating voltage of the Epro PR6424/104-000 sensor?
The operating voltage of the sensor is 24V DC, which is typical for many industrial sensors. -
What is the temperature range in which the Epro PR6424/104-000 can operate?
The sensor can operate in temperatures ranging from -20°C to +85°C, making it suitable for use in a variety of industrial settings. -
How is the Epro PR6424/104-000 sensor mounted?
The sensor can be thread-mounted and is adjustable for precise alignment and installation in different applications. -
Can the Epro PR6424/104-000 sensor be used in high-speed applications?
Yes, the PR6424/104-000 has a fast response time of less than 1 ms, making it suitable for high-speed applications such as vibration monitoring and displacement measurement.
