Product Overview
The Epro PR6424/106-101 16mm Eddy Current Sensor is designed for precise, non-contact measurement of displacement, vibration, and position in various industrial applications. Utilizing eddy current technology, this sensor operates by detecting changes in the electromagnetic field caused by the proximity of conductive materials, ensuring high-accuracy readings without physical contact with the target.
With its compact 16mm diameter, the PR6424/106-101 is ideal for applications where space is limited, such as in tight or confined spaces. The sensor is capable of providing both voltage and current outputs, allowing for easy integration with a variety of control systems and automation setups. Its fast response time, high sensitivity, and wide operating temperature range make it suitable for dynamic environments where rapid feedback and real-time adjustments are necessary.
The Epro PR6424/106-101 is commonly used in industries such as automotive, aerospace, industrial automation, and power generation, ensuring that machinery and equipment operate efficiently and reliably.
Product Parameters
| Parameter | Specification |
|---|---|
| Model Number | PR6424/106-101 |
| Measurement Principle | Eddy Current |
| Probe Diameter | 16 mm |
| Measuring Range | Up to 10 mm |
| Output Type | Analog (Voltage, Current) |
| Output Range | 0-10 V, 4-20 mA |
| Response Time | <1 ms |
| Operating Temperature | -20°C to 85°C |
| Operating Voltage | 15 to 30 VDC |
| Dimensions (Head) | Ø16 mm |
| Weight | 0.2 kg |
Product Applications
The Epro PR6424/106-101 16mm Eddy Current Sensor is ideal for a range of applications that require non-contact measurement of displacement, position, and vibration in dynamic environments. Key applications include:
-
Automotive Industry: Used for precise monitoring of displacement and vibration in engine components, transmissions, and other mechanical parts.
-
Aerospace: Essential for the position and vibration monitoring of critical components like turbine blades, compressors, and control surfaces in aircraft engines.
-
Industrial Automation: The sensor plays a critical role in monitoring moving parts, robotic arms, and conveyor belts, enhancing system efficiency and operational reliability.
-
Vibration Monitoring: It is widely used to monitor vibration in rotating machinery, motors, pumps, and compressors, helping identify potential failures before they occur.
-
Material Testing: Non-destructive testing applications use this sensor for measuring displacement, wear, and condition of metallic materials, offering high precision without physical contact.
-
Power Generation: In power plants, the sensor monitors turbines, generators, and other critical rotating equipment to ensure continuous operation and prevent breakdowns.
-
Mining and Oil & Gas: In these industries, the sensor is used for condition monitoring of equipment such as drilling rigs and heavy machinery, ensuring safe and efficient operation.
Advantages of the Product
The Epro PR6424/106-101 16mm Eddy Current Sensor offers several advantages, making it an ideal choice for industries requiring high-precision measurement:
-
Non-Contact Measurement: By using eddy current technology, the sensor performs measurements without making physical contact with the target, reducing wear and improving long-term reliability.
-
High Precision: The sensor offers excellent measurement accuracy, which is crucial for applications requiring detailed monitoring of mechanical movements and vibrations.
-
Compact Design: With a 16mm probe diameter, the sensor is ideal for use in constrained spaces where larger sensors may not fit, providing flexibility for installation.
-
Fast Response Time: The sensor responds in less than 1 millisecond, providing rapid feedback for systems that require real-time adjustments.
-
Wide Operating Temperature Range: The sensor operates in temperatures from -20°C to 85°C, making it suitable for a wide variety of industrial environments.
-
Multiple Output Options: With both voltage (0-10V) and current (4-20mA) outputs, the sensor offers compatibility with a variety of control systems and monitoring equipment.
-
Durability and Robustness: Designed to withstand electromagnetic interference and mechanical vibrations, the sensor offers reliable performance in harsh industrial environments.
-
High Sensitivity: The PR6424/106-101 is highly sensitive, detecting even minute changes in displacement and vibration, making it ideal for applications that require extreme precision.
FAQ
-
How does the Epro PR6424/106-101 sensor work?
-
The sensor uses eddy current technology to measure displacement or vibration. It generates an alternating magnetic field, which induces currents in the target. The sensor detects changes in these currents to calculate the distance or position of the target.
-
-
What output options does the PR6424/106-101 provide?
-
The sensor offers both voltage (0-10V) and current (4-20mA) output options, making it versatile for integration with various control systems and automation setups.
-
-
What is the measuring range of the Epro PR6424/106-101?
-
The PR6424/106-101 can measure up to 10 mm of displacement, making it suitable for a variety of applications requiring precise measurements of small movements.
-
-
What is the response time of the sensor?
-
The response time of the PR6424/106-101 is less than 1 millisecond, providing rapid feedback for fast-moving systems and dynamic applications.
-
-
What is the operating temperature range for this sensor?
-
The sensor operates effectively within a temperature range of -20°C to 85°C, ensuring reliable performance in both hot and cold industrial environments.
-
-
Can the sensor detect non-metallic materials?
-
No, the sensor works only with conductive materials, as the eddy current principle requires a metallic target to induce the necessary electromagnetic field.
-
-
What is the significance of the 16mm probe size?
-
The 16mm diameter of the sensor’s probe allows it to be used in tight spaces where larger sensors would be impractical, providing flexibility in installation.
-
-
How precise is the Epro PR6424/106-101 sensor?
-
The sensor offers high-precision measurements, allowing it to detect even small changes in displacement or vibration with great accuracy.
-
-
Can the sensor be used in high-speed applications?
-
Yes, the fast response time of less than 1 millisecond makes the PR6424/106-101 ideal for high-speed applications requiring quick adjustments and real-time feedback.
-
-
How does the Epro PR6424/106-101 handle electromagnetic interference?
-
The sensor is designed to be resistant to electromagnetic interference, ensuring stable and accurate measurements even in environments with high levels of electrical noise.
-
