Epro PR6424/108-101 16mm Eddy Current Sensor

Product Introduction

The Epro PR6424/108-101 is a high-precision 16mm Eddy Current Sensor, designed for non-contact measurement of displacement, vibration, and position in industrial applications. This sensor offers reliable and accurate performance, particularly in environments where traditional mechanical sensors would not be feasible or where minimal interference with the system is required. The Epro PR6424/108-101 provides direct measurement of the displacement of metallic objects without physical contact, making it ideal for monitoring rotating machinery, measuring shaft positions, and measuring radial or axial vibrations.

This sensor utilizes Eddy Current Technology, which enables highly sensitive measurements with fast response times and excellent repeatability. The non-contact measurement approach reduces wear and tear, enhancing the longevity and reliability of the system. With a 16mm sensor head diameter, the PR6424/108-101 is compact and easy to integrate into tight spaces within control systems and industrial machinery.

Product Specifications

Product Applications

The Epro PR6424/108-101 16mm Eddy Current Sensor is suitable for a wide range of applications across various industries. Its primary applications include:

• Machine Condition Monitoring: Used to measure vibration and displacement in rotating machinery such as motors, pumps, and turbines, helping prevent failures and ensuring optimal performance.

• Precision Measurement: Ideal for precise measurement of shaft positions, tool positions, and other critical parts where non-contact sensing is required to ensure accurate results.

• Rotating Equipment: Commonly used in power plants, manufacturing plants, and other industrial settings to measure the axial and radial displacement of shafts and rotating components.

• Automotive: Used in automotive manufacturing and testing processes to monitor the position and movement of parts in engines and mechanical systems.

• Aerospace: Applied in aerospace for vibration and displacement measurements in components such as engines, turbines, and control systems.

• Test Rigs: Employed in test benches and industrial test setups to monitor displacement or vibrations of test specimens without interference.

Product Advantages

• Non-contact Measurement: The key advantage of the PR6424/108-101 is its non-contact measurement, which eliminates wear and tear associated with traditional contact sensors.

• High Sensitivity and Accuracy: The Eddy Current Technology used in the sensor ensures high precision, making it suitable for monitoring sensitive equipment and components in high-performance environments.

• Fast Response Time: The sensor has a fast response time of less than 1 millisecond, allowing for real-time monitoring of dynamic processes and critical equipment.

• Durability: With its robust construction and IP65 protection rating, the sensor is highly resistant to dust and water, making it suitable for harsh industrial environments.

• Compact Design: The 16mm sensor head diameter allows for easy installation in confined spaces, making it highly versatile in industrial machinery and systems.

• Wide Operating Temperature Range: The sensor can operate in extreme temperatures, from -40°C to +85°C, making it suitable for diverse industrial applications and environments.

• Minimal Maintenance: As a non-contact sensor, it requires less maintenance compared to traditional contact-based sensors, contributing to lower operational costs and higher uptime.

FAQ

1. What types of signals does the Epro PR6424/108-101 sensor provide?

   • The sensor provides an analog output signal, available in 4-20 mA or 0-10 V depending on the configuration.

2. What is the measurement range of the Epro PR6424/108-101?

   • The measurement range typically spans from 10 mm to 50 mm, depending on the configuration of the sensor.

3. What is the operating temperature range of the sensor?

   • The sensor operates within a temperature range of -40°C to +85°C, suitable for both extreme cold and heat environments.

4. How is the Epro PR6424/108-101 sensor mounted?

   • The sensor is mounted via a threaded mounting system, allowing it to be securely integrated into various machinery and systems.

5. What is the response time of the Epro PR6424/108-101 sensor?

   • The sensor has a fast response time of less than 1 millisecond, allowing for real-time feedback in critical applications.

6. What is the power supply requirement for the Epro PR6424/108-101?

   • The sensor operates with a 15 to 30 V DC power supply.

7. Can the Epro PR6424/108-101 sensor be used in outdoor environments?

   • Yes, with its IP65 protection rating, the sensor is dust-tight and can withstand water jets, making it suitable for outdoor industrial applications.

8. What industries benefit from using the Epro PR6424/108-101?

   • The sensor is commonly used in power generation, automotive, aerospace, manufacturing, and testing industries.

9. What is the advantage of using an Eddy Current sensor like the PR6424/108-101?

   • Eddy Current sensors offer the key benefit of non-contact measurement, reducing wear on both the sensor and the machine parts being measured.

10. How accurate is the Epro PR6424/108-101 sensor?

    • The sensor provides high-precision measurements, ensuring that displacement and vibration readings are accurate and reliable for critical applications.
