The Epro PR6424/119-100 16 mm Eddy Current Sensor is a high-precision, non-contact displacement and position sensor that uses advanced eddy current technology. It is designed to measure the position, displacement, and vibration of moving parts in industrial applications, offering extremely accurate and reliable performance. This sensor operates without physical contact, eliminating issues such as wear, friction, and mechanical strain that are typically associated with traditional contact-based measurement systems.
With its compact 16 mm sensor head, the PR6424/119-100 is ideally suited for applications where space is limited and high precision is required. It is often used in machinery condition monitoring, process control, and vibration analysis, making it a vital component in critical industries such as manufacturing, automotive, aerospace, and energy.
The sensor’s robust design ensures long-term operation in harsh environments, with the ability to withstand temperature fluctuations, vibration, and electromagnetic interference. Whether used in rotating equipment, automated systems, or precision measurement setups, the Epro PR6424/119-100 provides fast, accurate, and reliable readings for critical applications.
Technical Specifications
The following table provides the technical specifications of the Epro PR6424/119-100 16 mm Eddy Current Sensor:
| Specification | Details |
|---|---|
| Model | PR6424/119-100 |
| Sensor Head Diameter | 16 mm |
| Weight | 0.2 kg |
| Measurement Principle | Eddy Current |
| Output Type | Analog (4-20 mA, 0-10 V) |
| Operating Distance | 1 mm to 8 mm (depending on configuration) |
| Accuracy | ±0.001 mm (typical) |
| Operating Temperature | -20°C to 85°C |
| Storage Temperature | -40°C to 100°C |
| Resolution | 0.001 mm |
| Supply Voltage | 10 to 30 VDC |
| Signal Output | 4 to 20 mA, 0 to 10 V (customizable) |
| Response Time | <1 ms |
| Protection Rating | IP67 (dust-tight, protected against immersion in water) |
Product Applications
The Epro PR6424/119-100 16 mm Eddy Current Sensor is widely used across multiple industries due to its high accuracy, reliability, and versatility. Key applications include:
-
Machine Condition Monitoring: Used to monitor the displacement, vibration, and condition of rotating machinery such as motors, pumps, and turbines.
-
Process Control: Provides precise measurements of key parameters in automated systems to ensure smooth and efficient operation.
-
Vibration Analysis: Ideal for detecting vibrations in machinery and equipment to prevent damage and enhance operational efficiency.
-
Position and Displacement Measurement: Employed in applications such as robotics, assembly lines, and conveyors to track the position of moving parts.
-
Turbine and Engine Monitoring: Crucial for detecting shifts and misalignments in turbine blades, engines, and other high-speed components.
-
Automotive Manufacturing: Used for quality control and monitoring precision parameters in automotive assembly lines.
-
Aerospace: Measures critical parameters in aerospace systems, ensuring that parts are functioning within safe operating limits.
Product Advantages
-
High Accuracy: The sensor provides excellent measurement accuracy of ±0.001 mm, making it ideal for high-precision applications.
-
Non-Contact Measurement: As a non-contact sensor, it eliminates mechanical wear and extends the lifespan of the system components.
-
Compact Design: With a 16 mm sensor head, the sensor is compact and can be easily integrated into tight spaces without compromising performance.
-
Versatile Output Options: The sensor supports both analog (4-20 mA) and digital (0-10 V) outputs, allowing for flexibility in system integration.
-
Fast Response Time: The sensor offers a fast response time of less than 1 ms, which is crucial for applications with rapidly changing measurement conditions.
-
Durability: With an IP67 protection rating, it is designed to operate reliably in harsh environments, offering protection against dust and water.
-
Wide Operating Temperature Range: The sensor operates in temperatures from -20°C to 85°C, making it suitable for use in extreme environments.
FAQ
1. What is the measurement principle of the Epro PR6424/119-100 sensor?
The Epro PR6424/119-100 uses the eddy current principle to measure displacement and position non-contact.
2. What type of output does the sensor provide?
The sensor provides analog output options, including 4-20 mA and 0-10 V, depending on the configuration.
3. What is the accuracy of the Epro PR6424/119-100 sensor?
The sensor offers a high accuracy of ±0.001 mm, making it suitable for precision measurements.
4. What is the operating distance range of the PR6424/119-100?
The operating distance for this sensor ranges from 1 mm to 8 mm, depending on the configuration.
5. What voltage is required for the Epro PR6424/119-100 sensor?
The sensor requires a supply voltage of 10 to 30 VDC.
6. How fast is the response time of the PR6424/119-100 sensor?
The sensor has a response time of less than 1 ms, enabling it to respond quickly to dynamic processes.
7. Can the Epro PR6424/119-100 sensor be used in outdoor applications?
Yes, the sensor has an IP67 rating, making it resistant to dust and water, which is ideal for outdoor use.
8. What is the operating temperature range for the Epro PR6424/119-100?
The operating temperature range is from -20°C to 85°C, making it suitable for a variety of industrial environments.
9. Is the sensor suitable for vibration monitoring?
Yes, the sensor is ideal for vibration analysis, detecting mechanical displacements and misalignments in rotating machinery.
10. Can the sensor output be customized?
Yes, the sensor’s output can be customized to suit different system requirements, offering both 4-20 mA and 0-10 V output options.
