Product Introduction
The Epro PR6426/010-130 is a high-precision eddy current displacement sensor designed for non-contact vibration and axial position measurements in rotating machinery. With a sensing diameter of 32 mm, this probe is part of Epro’s well-established PR6426 series and is tailored for large shaft or surface monitoring applications where accurate, reliable, and rugged sensing is essential.
When paired with the Epro CON041 or CON021 converter and the Epro MMS6000 monitoring system, the PR6426/010-130 forms a vital part of a complete condition monitoring and machinery protection solution. It is particularly well-suited for use in steam turbines, gas turbines, compressors, gearboxes, and large motors.
Product Specifications
| Parameter | Details |
|---|---|
| Model | PR6426/010-130 |
| Sensing Technology | Eddy Current (Non-contact displacement measurement) |
| Sensor Head Diameter | 32 mm |
| Measuring Range | Up to 4 mm (axial and radial displacement) |
| Output Signal | Proportional to distance (via CON041/CON021) |
| Frequency Response | DC to 10 kHz |
| Sensitivity | Approx. 7.87 mV/μm (depends on converter used) |
| Target Material | Typically ferromagnetic (e.g., steel) |
| Temperature Range (Operation) | –35°C to +180°C (probe only) |
| Vibration Limit | Up to 20 g |
| Shock Limit | 100 g peak |
| Pressure Resistance | Up to 10 bar (when properly mounted) |
| Electrical Connection | Coaxial cable to converter |
| Compatible Converters | CON041, CON021 |
| Housing Material | Stainless Steel |
| Mounting Thread | M14 x 1.5 mm or other (depending on model) |
| Protection Class | IP68 (fully sealed, immersion-proof) |
| Weight | 0.8 kg |
| Certification | CE, ATEX, IECEx (optional depending on version) |
Product Applications
-
Turbomachinery Monitoring: Ideal for steam turbines, gas turbines, and turbo-compressors to measure shaft displacement and rotor position.
-
Hydroelectric Generators: Used to monitor radial or axial displacement in large rotating shafts.
-
Pumps and Fans: Ensures alignment and dynamic balance are maintained during operation.
-
Gearboxes and Bearings: Detects early signs of bearing wear, shaft bending, or gear misalignment.
-
Critical Machinery Protection Systems: Part of the Epro online monitoring systems (MMS6000), enabling shutdowns on abnormal movement detection.
Product Advantages
-
High Precision Measurement: Non-contact eddy current technology provides extremely accurate displacement readings with high repeatability.
-
Rugged Industrial Design: Built from corrosion-resistant stainless steel, suitable for harsh and high-temperature environments.
-
Versatile Integration: Fully compatible with CON041 and CON021 converters and Epro MMS series for complete monitoring setups.
-
Long-Term Reliability: Stable signal characteristics over time reduce maintenance frequency and improve system availability.
-
Wide Operating Range: Withstands extreme temperatures, pressures, and vibrations common in heavy-duty industrial environments.
-
Customizable Configurations: Thread type, cable length, and calibration range can be tailored to specific machinery requirements.
Frequently Asked Questions (FAQ)
-
Q: What is the measuring range of the PR6426/010-130 sensor?
A: The sensor typically measures up to 4 mm of displacement, depending on the converter used. -
Q: Can this sensor operate in high-temperature environments?
A: Yes, the PR6426/010-130 operates reliably up to +180°C. -
Q: What is the thread size for mounting?
A: The standard mounting thread is M14 x 1.5 mm, though other options are available. -
Q: Is the sensor resistant to moisture or immersion?
A: Yes, it has an IP68 rating, making it fully sealed and immersion-resistant. -
Q: Which converter modules are compatible with this probe?
A: The PR6426 series is compatible with CON041 and CON021 converter modules. -
Q: Is this sensor suitable for non-ferromagnetic targets?
A: No, it is calibrated for ferromagnetic materials like steel. -
Q: How is the sensor signal transmitted?
A: The output is transmitted via coaxial cable to the converter, which processes the signal. -
Q: What types of faults can it help detect?
A: Shaft misalignment, eccentricity, rotor rubs, and excessive axial movement. -
Q: Can this be used in explosive atmospheres?
A: Yes, ATEX and IECEx certified versions are available for hazardous areas. -
Q: What maintenance does this sensor require?
A: Minimal; only occasional inspection for cable integrity and probe alignment is recommended.
Related Models (Same Series or Function)
| Model | Sensing Diameter | Measuring Range | Thread Type | Temperature Rating |
|---|---|---|---|---|
| PR6426/000-030 | 8 mm | 1 mm | M8 x 1.0 | –35°C to +180°C |
| PR6426/002-030 | 11 mm | 2 mm | M10 x 1.0 | –35°C to +180°C |
| PR6426/005-030 | 25 mm | 4 mm | M30 x 2.0 | –35°C to +180°C |
| PR6426/009-130 | 50 mm | 6 mm | M50 x 2.0 | –35°C to +180°C |
| PR6423/010-030 | 32 mm | 4 mm | M32 x 2.0 | –35°C to +180°C |
| PR6424/010-100 | 32 mm | 4 mm | M32 x 2.0 | –35°C to +350°C (high-temp) |
Popular Models from the Same Brand (Epro/Philips)
| Model | Description | Type | Application |
|---|---|---|---|
| PR6423/000-030 | Eddy current sensor, 8 mm, 1 mm range | Proximity Sensor | General industrial monitoring |
| PR6424/010-140 | High-temp eddy current probe, 32 mm | Proximity Sensor | Turbines, extreme environments |
| CON041 | Converter module for PR6426 series | Converter | Signal conditioning |
| MMS6312 | Monitoring system for vibration/position | Monitoring System | Machinery protection |
| CON021 | Compact converter for PR6423/PR6426 series | Converter | Space-constrained installations |
| MMS3120 | Multichannel vibration monitoring module | Monitoring System | Turbine, compressor diagnostics |
