The Epro PR6453/201-SDR 12.5mm Eddy Current Sensor is a precision non-contact displacement and vibration transducer developed for high-performance industrial condition monitoring systems. It belongs to the Epro PR6453 series, a family of eddy current sensors optimized for accurate detection of shaft displacement, axial position, and vibration in rotating machinery.

This sensor operates on the eddy current measurement principle, generating a magnetic field that interacts with the conductive target surface. The resulting change in impedance is translated into an analog signal proportional to the distance between the probe tip and the target. The PR6453/201-SDR combines high resolution, stable signal output, and robust construction, making it ideal for use in harsh environments where precision and reliability are crucial.

Designed for use with compatible Epro signal converters such as CON021 or CON041, this sensor offers seamless integration with advanced monitoring systems like the Epro MMS series. With a 12.5 mm sensing head, it provides a balance between compact design and measurement range, enabling accurate monitoring of small or medium-sized shafts in turbines, compressors, motors, and other critical rotating machines.

---

Technical Specifications

---

Applications

The PR6453/201-SDR is specifically designed for applications requiring precise, continuous measurement of shaft displacement, vibration, or position in dynamic machinery environments. Its non-contact nature allows reliable operation in systems where mechanical sensors would quickly degrade.

Typical application fields include:

• Steam and Gas Turbines: Used for shaft displacement, eccentricity, and vibration monitoring to prevent bearing or rotor failures.

• Compressors and Pumps: Measures shaft position and imbalance for predictive maintenance programs.

• Electric Motors and Generators: Provides early detection of misalignment, rotor bowing, and bearing wear.

• Gearboxes and Transmission Systems: Detects gear mesh misalignment, excessive vibration, and shaft deflection.

• Machinery Protection Systems: Integrated with Epro MMS series for automatic alarm and trip functions.

• Industrial Automation Systems: Enables feedback control for precision motion and rotation applications.

The PR6453/201-SDR’s small sensing diameter makes it particularly useful where compact installation and high sensitivity are required, such as small turbine bearings or compact motor assemblies.

---

Advantages

The Epro PR6453/201-SDR offers a range of advantages that make it an excellent choice for long-term industrial monitoring and protection applications:

• Non-Contact Sensing Technology: Eliminates mechanical wear, ensuring long operational life and stable measurement.

• High Precision and Linearity: Maintains measurement accuracy across the full operating range.

• Wide Frequency Response: Enables detection of both slow shaft displacement and high-frequency vibration components.

• Compact Design: The 12.5 mm sensing head allows installation in tight spaces or small machinery housings.

• Temperature Resilience: Operates reliably up to +180°C, suitable for turbines and high-temperature rotating equipment.

• Strong Signal Integrity: Shielded probe design minimizes electromagnetic and radio frequency interference.

• Easy Integration: Fully compatible with Epro’s CON021 and CON041 converters and monitoring systems.

• Rugged Construction: Resistant to oil, dust, and vibration, making it ideal for harsh industrial environments.

• Consistent Output Stability: Delivers reliable readings even in the presence of vibration, electrical noise, or temperature variation.

• Low Maintenance Requirements: Designed for continuous use with minimal need for recalibration or service.

---

FAQ

1. What type of physical quantity does the PR6453/201-SDR measure?
   It measures the displacement and vibration of metallic targets using the non-contact eddy current principle.

2. Which converter should be used with this sensor?
   The sensor is designed to work with Epro’s CON021 or CON041 converters for accurate signal conditioning.

3. Can this sensor measure both static and dynamic parameters?
   Yes, it measures both static shaft displacement and dynamic vibration simultaneously.

4. What kind of target materials are compatible with this sensor?
   The probe is optimized for ferromagnetic metals such as carbon steel, iron, and nickel-based alloys.

5. What is the typical frequency response range?
   The frequency response typically spans from 0.5 Hz to 20 kHz, suitable for various rotating machinery speeds.

6. How does the sensor maintain accuracy under temperature variations?
   Its electronic components are temperature-compensated, ensuring minimal drift over a wide thermal range.

7. Is the sensor compatible with third-party monitoring systems?
   Yes, the conditioned output from Epro converters can be integrated into most standard industrial monitoring systems.

8. Can multiple sensors be used simultaneously in one system?
   Yes, multiple sensors can be configured for multi-axis or multi-point monitoring within a single system.

9. What is the sensor’s protection level against environmental exposure?
   It has an IP65 protection rating, ensuring resistance against dust, oil, and moisture intrusion.

10. How is electromagnetic interference minimized?
    The sensor and connecting cable are shielded, and differential signal transmission minimizes external noise effects.

---
