Epro PR6453/240-101 12.5mm Eddy Current Sensor

Company Information
E-mail		[email protected]
Mobile		+8613666033393
Whatsapp		+8613666033393
WeChat		13666033393
Add		Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Introduction

The Epro PR6453/240-101 12.5mm Eddy Current Sensor is a precision-engineered, non-contact displacement and vibration sensor designed for high-reliability condition monitoring and machinery protection applications. As part of Epro’s PR6453 series, this model delivers exceptional accuracy and long-term stability in demanding industrial environments such as power plants, refineries, and manufacturing facilities.

Operating on the eddy current principle, the PR6453/240-101 detects the distance between the probe tip and a conductive target surface, converting this information into an analog signal. This allows it to precisely measure shaft displacement, vibration, and position without physical contact, eliminating mechanical wear and reducing maintenance needs.

The sensor features a 12.5 mm sensing head, optimized for compact installation spaces where smaller shafts or confined machinery housings are present. When combined with Epro’s CON021 or CON041 converter, the system provides a linearized, temperature-compensated output that integrates easily into Epro’s MMS monitoring systems or other industrial control platforms.

With high electromagnetic resistance, excellent linearity, and robust construction, the PR6453/240-101 represents an ideal solution for continuous monitoring of rotating machinery such as turbines, compressors, and motors in critical operational environments.

---

Technical Specifications

---

Applications

The Epro PR6453/240-101 is used for precision measurement and monitoring in a wide range of rotating machinery applications. Its ability to detect both static displacement and dynamic vibration makes it an essential component in machinery protection systems.

Primary application areas include:

• Turbomachinery Monitoring: Detects shaft displacement, axial movement, and vibration in steam and gas turbines.

• Compressors and Pumps: Measures rotor position and imbalance to prevent bearing and seal failures.

• Electric Motors and Generators: Provides real-time monitoring of shaft behavior to identify misalignment or mechanical looseness.

• Gearboxes and Transmission Systems: Detects excessive vibration or misalignment in rotating drive systems.

• Process Industry Equipment: Operates reliably in high-temperature, oil-contaminated, and vibration-intensive environments.

• Machinery Protection Systems: Works seamlessly with Epro MMS systems or PLC-based control units for automated fault detection.

This sensor is widely used in predictive maintenance systems, enabling early detection of potential mechanical failures, reducing downtime, and extending equipment lifespan.

---

Advantages

The PR6453/240-101 12.5mm Eddy Current Sensor provides numerous operational and performance benefits that make it a trusted choice for critical industrial applications:

• Non-Contact Measurement: Provides precise readings without physical wear, ensuring long-term reliability.

• High Sensitivity and Stability: Maintains accurate output under fluctuating environmental conditions.

• Wide Frequency Range: Measures both low-speed shaft displacement and high-frequency vibration signals.

• Compact Form Factor: The 12.5 mm head allows installation in confined machinery spaces or small bearing housings.

• Thermal Resilience: Operates effectively up to +180°C, making it suitable for turbines and high-temperature processes.

• Excellent Signal Quality: Shielded probe design minimizes electromagnetic interference and noise distortion.

• Seamless Integration: Fully compatible with Epro converters and monitoring platforms.

• Durable Construction: Built to withstand harsh industrial environments involving oil, dust, and mechanical shock.

• Low Maintenance Requirements: Requires no calibration during normal service operation.

• Long-Term Operational Stability: Maintains consistent linearity and sensitivity across extended periods of use.

---

FAQ

1. What physical quantity does this sensor measure?
   It measures the displacement and vibration of a metallic target using the eddy current principle.

2. Which converter should be used with this sensor?
   It is compatible with Epro CON021 or CON041 converters for signal processing and output conditioning.

3. Can the sensor be used in high-temperature environments?
   Yes, it can operate reliably in ambient temperatures up to +180°C.

4. Is it possible to measure both static and dynamic signals with this sensor?
   Yes, the sensor can detect both static shaft position and dynamic vibration simultaneously.

5. What type of materials can be used as targets?
   The sensor is designed for ferromagnetic materials such as steel, iron, and nickel alloys.

6. How is the output signal transmitted to the monitoring system?
   The raw signal is conditioned by the converter and transmitted as a differential analog voltage output.

7. What is the typical frequency response of the sensor?
   It has a frequency response range of approximately 0.5 Hz to 20 kHz.

8. How is electromagnetic interference reduced?
   The sensor and its cable assembly are fully shielded, and differential signal transmission minimizes external noise.

9. Can this sensor be integrated with other monitoring platforms besides Epro?
   Yes, the conditioned output from the converter can interface with most third-party monitoring and control systems.

10. Does the sensor require periodic calibration?
    No, under normal operation it remains stable and does not require frequent recalibration.

---
