Product Overview
The Epro PR6480/2E1-000 is a high-precision eddy current sensor designed for accurate measurement of displacement, position, and vibration in critical industrial applications. Utilizing the eddy current induction principle, this sensor provides non-contact measurement, ensuring precise readings without the need for physical contact. The PR6480/2E1-000 sensor is ideal for monitoring the health of machinery and systems where traditional contact-based sensors would cause wear or reduce measurement accuracy.
Built to operate in a wide range of harsh environments, the Epro PR6480/2E1-000 is perfect for applications in condition monitoring, vibration analysis, and machine health diagnostics. Its customizable design options allow it to integrate seamlessly into a variety of industrial systems, making it suitable for industries such as automotive, aerospace, energy, and manufacturing.
Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | PR6480/2E1-000 |
| Sensing Technology | Eddy current |
| Probe Diameter | Optional (customizable) |
| Shipping Weight | 3 kg |
| Measuring Range | Up to 20 mm (depending on probe) |
| Output Signal | 4-20 mA, 0-10 V (configurable) |
| Temperature Range | -40°C to +120°C |
| Linearity | ≤ ±0.05% of full scale |
| Power Supply | 24 VDC ±10% |
| Housing Material | Stainless steel |
| Enclosure Protection | IP67 |
Applications
The Epro PR6480/2E1-000 sensor is specifically designed for high-precision non-contact measurement in industrial settings. Common applications include:
-
Condition Monitoring: Used to continuously monitor the condition of rotating machinery, such as turbines, motors, and compressors, detecting early signs of wear and ensuring reliable operation.
-
Vibration Analysis: Helps detect vibration and displacement in machinery, allowing for predictive maintenance and minimizing unexpected breakdowns.
-
Machine Alignment: Vital in aligning precision machinery during installation or regular maintenance.
-
Power Generation: Used for rotor-to-stator gap measurement in turbine generators and other critical machinery.
-
Aerospace: Applied in aerospace components to measure displacement and detect faults in high-speed machinery.
-
Automotive: Used for vibration and displacement measurement in automotive manufacturing processes.
Advantages
-
Non-Contact Measurement: The sensor uses eddy current technology, eliminating the need for contact and reducing wear.
-
High Precision: The PR6480/2E1-000 offers linearity of ±0.05% of full scale, ensuring precise and reliable measurements.
-
Wide Temperature Range: It operates effectively across a temperature range of -40°C to +120°C, making it suitable for diverse industrial environments.
-
Durable Construction: The sensor’s stainless steel housing and IP67 rating ensure resistance to harsh conditions, including dust, water, and chemical exposure.
-
Flexible Output Options: The sensor supports both 4-20 mA and 0-10 V output signals, providing compatibility with a wide range of industrial control systems.
-
Customizable Probe Diameter: The sensor’s probe diameter is optional and can be customized for specific application requirements.
-
Low Maintenance: With no moving parts, the sensor requires less maintenance and reduces the risk of failure due to wear.
-
Robust for Harsh Environments: The IP67 protection rating ensures that the sensor operates reliably in extreme environments, including wet, dusty, and corrosive areas.
-
Enhanced Signal Integrity: The sensor produces high-quality, noise-free signals for accurate, real-time measurements.
-
Versatility: It is highly adaptable to a wide range of industrial monitoring applications, from machinery health to precision measurement tasks.
FAQ
-
What output signal does the Epro PR6480/2E1-000 sensor provide?
The sensor supports configurable output signals, including 4-20 mA and 0-10 V, ensuring easy integration with industrial systems. -
What is the maximum measuring range of the PR6480/2E1-000?
The measuring range of the sensor can reach up to 20 mm, depending on the probe configuration and application. -
What is the linearity of the PR6480/2E1-000 sensor?
The PR6480/2E1-000 offers linearity of ±0.05% of full scale, providing high accuracy in measurements. -
What is the operating temperature range for this sensor?
The sensor operates within a temperature range of -40°C to +120°C, suitable for use in both extreme cold and heat. -
Can the probe diameter be customized for specific applications?
Yes, the probe diameter of the PR6480/2E1-000 is optional and can be customized based on the specific needs of the application. -
What industries benefit most from the PR6480/2E1-000?
This sensor is highly beneficial in industries such as power generation, aerospace, automotive, and manufacturing where precision displacement and vibration measurements are critical. -
What is the power supply requirement for the PR6480/2E1-000?
The sensor operates on a 24 VDC power supply, with a tolerance of ±10%. -
How is the Epro PR6480/2E1-000 sensor different from contact-based sensors?
Unlike contact-based sensors, the PR6480/2E1-000 uses eddy current technology, which eliminates mechanical wear and friction, ensuring longer lifespan and greater accuracy. -
Is the Epro PR6480/2E1-000 suitable for harsh environments?
Yes, the sensor is designed with a stainless steel housing and an IP67 rating, providing protection against dust, moisture, and harsh environmental factors. -
Can the Epro PR6480/2E1-000 sensor be used for multi-axis measurements?
Yes, it can be configured for multi-axis displacement measurements by using multiple sensors in combination with control systems.
Similar Models
| Model Number | Description |
|---|---|
| PR6480/2E2-000 | High-precision version with extended measuring range for larger machinery |
| PR6480/2E3-000 | Compact version for space-constrained applications |
| PR6480/2E4-000 | High-temperature version for extreme environments |
| PR6480/2E5-000 | Dual-channel version for multi-point displacement measurement |
| PR6480/2E6-000 | Enhanced signal processing for high-frequency applications |
| PR6480/2E7-000 | Sensor with integrated feedback for continuous adjustment |
Popular Epro Models
| Model Number | Description |
|---|---|
| PR6480/100-000 | General-purpose eddy current sensor for vibration monitoring |
| PR6480/120-000 | Compact sensor designed for tight installation spaces |
| PR6480/140-000 | High-performance version for precision displacement measurements |
| PR6480/160-000 | Long-range sensor for large-scale machinery monitoring |
| PR6480/180-000 | High-resolution sensor for ultra-precise measurements in critical systems |
| PR6480/190-000 | Multi-axis sensor for complex measurement systems |
