The GE DS200CPCAG1ABB Mark V Contactor Pilot Board is a compact industrial control module designed to manage and interface with contactor operations within GE Mark V turbine and drive control systems. It serves as an intermediary between the control processor and field contactors, enabling precise switching, monitoring, and coordination of power circuits.
This board is engineered to provide reliable pilot control of contactors, ensuring consistent actuation and de-actuation signals. Its compact design and robust construction allow it to operate in tight control cabinet spaces while maintaining high electrical reliability and mechanical stability.
The DS200CPCAG1ABB supports continuous-duty operation in industrial environments, offering predictable performance and enhanced system safety by providing accurate control of high-power devices through low-level control logic.
Product Specifications
| Parameter | Description |
|---|---|
| Product Type | Contactor Pilot Board |
| System Series | GE Mark V Control System |
| Primary Function | Pilot control of contactors and high-power switching devices |
| Signal Category | Discrete control and monitoring signals |
| Control Method | Low-voltage pilot signals to actuate field contactors |
| System Interface | Backplane connection to control rack |
| Electrical Isolation | Isolation between control logic and high-power circuits |
| Operating Environment | Industrial-grade temperature and vibration tolerance |
| Installation Method | Rack-mounted or compact panel installation |
| Diagnostics Capability | Pilot status and fault indication |
| Dimensions | 150 × 100 × 20 mm |
| Weight | 0.113 kg |
Applications
• Turbine and generator control, providing pilot actuation of contactors in critical power circuits.
• Industrial drive systems, managing contactors for braking, motor startup, and auxiliary circuits.
• High-power switching supervision, enabling accurate monitoring of field devices via pilot signals.
• Safety and interlock circuits, ensuring reliable activation and deactivation of protective contactors.
• Control system upgrades, offering a compact replacement or expansion module for Mark V contactor control.
Advantages
• Compact and space-efficient, ideal for control cabinets with limited installation space.
• Reliable contactor control, ensuring consistent and predictable actuation of high-power devices.
• Electrical isolation, protecting control electronics from field-side power transients.
• Direct system compatibility, designed for seamless integration with GE Mark V architectures.
• Enhanced maintainability, with clear status indication for easy troubleshooting and inspection.
• Continuous-duty reliability, supporting stable operation in demanding industrial environments.
