The GE DS200TCTGG1AEE Relay Board is a discrete output module designed for GE DS200 control and monitoring systems. It provides electrically isolated relay outputs to interface system logic with field devices such as alarms, actuators, and control circuits.
This board enables reliable switching of discrete loads while maintaining electrical isolation, protecting system electronics from voltage spikes and ensuring deterministic operation. It is commonly used in applications where alarm signaling, control actuation, and safety interlocks are required in industrial processes and machinery monitoring systems.
With its robust design, the DS200TCTGG1AEE supports continuous-duty operation and integration into VME or backplane-based control architectures, making it suitable for mission-critical industrial applications.
Product Specifications
| Specification Item | Technical Description / Value |
|---|---|
| Model Number | DS200TCTGG1AEE |
| Product Type | Relay Board |
| Output Type | Electrically isolated relay outputs |
| Number of Channels | Configurable discrete outputs |
| Load Handling | Field actuators, alarms, and control circuits |
| System Compatibility | GE DS200 control and monitoring systems |
| Functional Role | Discrete signal output for control and protection |
| Electrical Isolation | Provides isolation between system electronics and field loads |
| Dimensions | 210 × 150 × 35 mm |
| Weight | 0.8 kg |
Applications
• Control of field devices including alarms, actuators, and indicators
• Safety interlock and protection systems requiring deterministic relay outputs
• Industrial process control for machinery and plant equipment
• Integration with DS200 modules for expanded discrete output capacity
• Distributed control systems where electrical isolation of outputs is required
• Mission-critical monitoring systems requiring reliable switching of signals
Advantages
• Electrically isolated relay outputs protect system electronics from load-induced disturbances
• Reliable discrete switching supports accurate control and protection actions
• Configurable output channels allow flexible system integration
• Supports continuous industrial operation with high reliability
• Compact and robust design suitable for rack or backplane mounting
• High compatibility with GE DS200 systems simplifies system expansion
• Enables safe interfacing between low-voltage electronics and higher-voltage field devices
