Product Overview
The GE Fanuc IC200UEX636 is a 6-channel analog expansion module in the VersaMax Micro series, designed to extend the analog I/O capabilities of compact PLC systems. It provides 4 analog inputs and 2 analog outputs, supporting both voltage and current signals. This module is ideal for applications requiring precise analog signal processing, such as sensor integration, feedback control, and monitoring.
Key Features
-
Analog I/O Configuration: 4 analog inputs and 2 analog outputs, totaling 6 I/O points
-
Signal Types: Supports both voltage (0–10V) and current (4–20mA) signals
-
Power Supply: Operates on 120/240 VAC power supply
-
Mounting: DIN rail mounting for easy integration into control panels
-
Hot-Swappable: Supports hot insertion and removal, allowing for maintenance without shutting down the system
-
Compatibility: Fully compatible with VersaMax Micro CPUs and expansion modules, enabling scalable system configurations
Technical Specifications
| Specification | Details |
|---|---|
| Model | IC200UEX636 |
| Series | VersaMax Micro |
| Analog Inputs | 4 × 0–10V or 4–20mA |
| Analog Outputs | 2 × 0–10V or 4–20mA |
| Power Supply | 120/240 VAC |
| Mounting | DIN Rail |
| Dimensions | 95 × 90 × 76 mm |
| Weight | 0.5 kg |
| Operating Temperature | 0°C to +60°C |
| Humidity | 5% to 95% non-condensing |
Frequently Asked Questions (FAQ)
1. What is the primary function of the IC200UEX636?
It serves as an analog expansion module to increase the analog I/O capacity of VersaMax Micro PLC systems by providing 4 analog inputs and 2 analog outputs.
2. What types of signals does the module support?
It supports both voltage (0–10V) and current (4–20mA) signals.
3. What is the required power supply for this module?
The module operates on a 120/240 VAC power supply.
4. Can it be replaced without shutting down the system?
Yes, it supports hot-swapping, allowing maintenance without system downtime.
5. How is the module mounted?
It is designed for DIN rail mounting, simplifying installation in control panels.
6. Is the IC200UEX636 compatible with other VersaMax modules?
Yes, it is fully compatible with VersaMax Micro CPUs and expansion modules.
7. What is the operating temperature and humidity range?
The module operates between 0°C and +60°C and can tolerate 5% to 95% non-condensing humidity.
8. How many I/O points does the module provide in total?
It provides a total of 6 I/O points, including 4 analog inputs and 2 analog outputs.
