Product Overview
The GE Fanuc IC693PTM100 is a Power Sensor Module designed for use with the Series 90-30 programmable logic controllers (PLCs). This module is primarily used to measure electrical power parameters, including voltage, current, and power for monitoring and controlling industrial automation processes. It enables precise real-time measurement and feedback of electrical power consumption, providing operators with critical information to optimize system performance, reduce energy costs, and maintain the reliability of electrical systems.
The IC693PTM100 is essential in applications where accurate energy monitoring is required, such as in motors, drives, pumps, and other electrical devices in industrial plants. The module is compatible with Series 90-30 PLCs, enabling seamless integration into existing control systems for continuous monitoring and control.
Key Features
-
Real-Time Power Monitoring: Measures voltage, current, and power for electrical devices and systems
-
Wide Voltage Range: Compatible with a broad range of input voltages for flexibility in various applications
-
Compact Design: Saves space in control cabinets while offering powerful monitoring capabilities
-
High Accuracy: Provides precise measurements for energy optimization and system diagnostics
-
Direct Interface to PLC: Easily integrates with Series 90-30 PLCs via dedicated communication ports
-
Field Calibration: Allows for adjustments to ensure measurement accuracy over time
-
Diagnostics Support: Offers data collection and diagnostic feedback for system troubleshooting
-
Energy Efficiency: Provides essential data for energy-saving measures and monitoring overall system performance
-
Operating Temperature Range: Designed to operate in a wide temperature range to accommodate industrial environments
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | IC693PTM100 |
| Product Type | Power Sensor Module |
| Input Voltage Range | 0–400 VAC |
| Current Measurement | 0–5 A (AC) |
| Power Measurement | Active power (kW), reactive power (kVAR) |
| Accuracy | ±1% of reading |
| Interface | Direct connection to Series 90-30 PLCs |
| Mounting | DIN rail mountable (35 mm) |
| Operating Temperature | -20°C to +60°C (-4°F to +140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Humidity | 5% to 95% RH, non-condensing |
| Power Supply | 24 VDC nominal |
| Dimensions | 120 x 100 x 30 mm |
| Weight | 0.25 kg |
| Compliance | CE, UL, RoHS, CSA |
Industry Applications
-
Energy Management: Monitors power consumption across industrial equipment to optimize energy efficiency
-
Manufacturing: Provides real-time feedback for machinery and assembly lines requiring precise energy control
-
HVAC Systems: Measures and monitors the power usage of heating, ventilation, and air conditioning systems
-
Motors & Drives: Measures current and voltage to optimize the performance of industrial motors and drives
-
Renewable Energy: Used for monitoring electrical power systems in solar or wind energy applications
-
Pumps & Compressors: Enables accurate energy monitoring of pumps and compressors in critical processes
Product Advantages
-
Accurate Power Measurements: Enables precise monitoring of both active and reactive power to improve system efficiency
-
Compact & Efficient: Saves space in control cabinets, making it ideal for systems with limited panel space
-
Enhanced Diagnostics: Provides valuable data for troubleshooting power-related issues and ensuring uptime
-
Cost-Efficient Energy Management: Helps reduce energy costs by offering insights into energy consumption and system performance
-
Rugged Industrial Design: Built to withstand harsh conditions commonly found in industrial settings
-
Simple Integration: Easy integration with Series 90-30 PLCs, minimizing setup time and maximizing system performance
-
Reliability in Harsh Environments: Operates in a wide range of environmental conditions, ensuring reliable operation in varying temperatures and humidity levels
Frequently Asked Questions (FAQ)
-
Q: What types of power does the IC693PTM100 measure?
A: It measures active power (kW) and reactive power (kVAR) for efficient system monitoring. -
Q: What is the input voltage range for the IC693PTM100?
A: The module supports an input voltage range of 0 to 400 VAC. -
Q: What is the maximum current measurement supported by the module?
A: The IC693PTM100 can measure up to 5 A AC. -
Q: Can the module be integrated with other PLCs besides the Series 90-30?
A: The module is designed specifically for Series 90-30 PLCs, and compatibility with other PLCs may require additional interface equipment. -
Q: How does the module handle field calibration?
A: The IC693PTM100 supports field calibration, allowing adjustments for more accurate readings over time. -
Q: Does the IC693PTM100 offer real-time diagnostics?
A: Yes, it offers real-time diagnostics and feedback for quick troubleshooting and maintenance. -
Q: What is the power supply requirement for this module?
A: The IC693PTM100 operates on a 24 VDC nominal power supply. -
Q: What are the operating conditions of the module?
A: It operates in a temperature range from -20°C to +60°C and can handle 5% to 95% RH. -
Q: Is the module suitable for energy-saving applications?
A: Yes, it is ideal for energy management systems where accurate power measurement is required to optimize energy use. -
Q: What are the installation requirements for the IC693PTM100?
A: It can be easily installed on a DIN rail with standard mounting dimensions (35 mm).
Related or Similar GE Fanuc Models
| Model Number | Description |
|---|---|
| IC693PTM200 | Power Meter Module for measuring electrical parameters |
| IC693PWR330 | Power Supply Module for Series 90-30 |
| IC693MDL730 | 8-Point 24VDC Output (Pos/Neg Logic) Module |
| IC693MDL940 | 16-Point Relay Output Module |
| IC693DSM314 | Axis Motion Control Module |
| IC693APU300 | High-Speed Counter Module |
Popular GE Fanuc Modules (Same Brand)
| Model Number | Description |
|---|---|
| IC693MDL740 | 16-Point 24VDC Output (Pos/Neg Logic) Module |
| IC693MDL931 | 16-Point 120VAC Input Module |
| IC693ALG220 | 4-Channel Analog Output Module |
| IC693APU300 | High-Speed Counter Module |
| IC693DSM314 | Motion Control Module for Servo or Stepper Motors |
| IC693ACC301 | RS-232 Serial Cable for Programmer Connection |
