The GE Fanuc IC697ALG320 is a high-performance analog output module designed for the PACSystems RX7i and RX3i platforms. It provides precise analog current or voltage output signals used to control various industrial field devices such as valves, actuators, drives, and other instrumentation requiring accurate analog control.
Featuring 16 channels of analog output with configurable ranges, the IC697ALG320 supports both current (4-20 mA) and voltage (±10 V) output modes, enabling versatile application across numerous industrial sectors. The module’s high resolution and fast update rates make it ideal for process control, automation, and systems demanding precise and reliable analog output.
Key Features
-
16 Analog Output Channels per module
-
Supports both 4-20 mA current and ±10 V voltage output ranges
-
High resolution (14-bit DAC) for precise control
-
Independent channel configuration and diagnostics
-
Fast update rates with simultaneous channel updates
-
Built-in diagnostics and status indicators
-
Compatible with PACSystems RX7i and RX3i platforms
-
Robust design for industrial environments
-
Isolation and short-circuit protection per channel
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | IC697ALG320 |
| Product Type | Analog Output Module |
| Platform Compatibility | PACSystems RX7i, RX3i |
| Number of Channels | 16 analog output channels |
| Output Signal Types | Current (4-20 mA), Voltage (±10 V) |
| Resolution | 14-bit DAC |
| Accuracy | ±0.1% of full scale |
| Update Rate | <1 ms per channel |
| Channel Isolation | Yes, channel-to-channel and channel-to-ground isolation |
| Protection | Short-circuit, open-circuit, and overload protection |
| Power Requirements | 5 VDC from backplane |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to 185°F) |
| Humidity | 5% to 95% RH, non-condensing |
| Dimensions | 100 x 25 x120 mm |
| Weight | 0.3 kg |
| Compliance | CE, UL, RoHS, CSA |
Industry Applications
-
Process Control: Precise control of valves, dampers, and actuators in manufacturing processes
-
Energy Sector: Managing output signals for turbines, generators, and power distribution
-
Water/Wastewater Treatment: Controlling pumps, flow meters, and chemical dosing equipment
-
Oil & Gas: Automation of drilling, refining, and safety control systems
-
Food & Beverage: Maintaining precise analog control in processing and packaging
-
HVAC Systems: Regulating temperature and airflow control devices
Product Advantages
-
High Channel Density: 16 output channels in a single compact module reduce panel space requirements
-
Dual Output Modes: Supports both current and voltage outputs for flexible applications
-
Excellent Accuracy and Resolution: 14-bit DAC ensures precise analog signal control
-
Robust Protection Features: Safeguards channels from electrical faults for reliable operation
-
Fast Response Time: Supports rapid process adjustments and control loops
-
Easy Integration: Seamlessly connects with PACSystems RX7i and RX3i controllers
-
Comprehensive Diagnostics: Facilitates quick fault detection and maintenance
Frequently Asked Questions (FAQ)
-
Q: How many analog output channels does the IC697ALG320 provide?
A: It provides 16 independent analog output channels. -
Q: Can the module output both current and voltage signals?
A: Yes, it supports both 4-20 mA current and ±10 V voltage outputs. -
Q: What is the output resolution of this module?
A: It offers a 14-bit digital-to-analog converter (DAC) for high precision. -
Q: Is the module compatible with all PACSystems controllers?
A: It is compatible with PACSystems RX7i and RX3i platforms. -
Q: What types of protections are included?
A: The module includes short-circuit, open-circuit, and overload protection on each channel. -
Q: What is the typical update rate for output signals?
A: The module supports update times of less than 1 millisecond per channel. -
Q: Does the module support diagnostics?
A: Yes, it features diagnostic LEDs and channel fault reporting. -
Q: Can individual channels be configured differently?
A: Yes, each channel can be configured independently. -
Q: What are the environmental operating conditions?
A: The module operates between 0°C and +60°C, with relative humidity of 5% to 95% (non-condensing). -
Q: How is the module mounted?
A: It mounts on a standard DIN rail compatible with the PACSystems platform.
