Product Overview
The GE Fanuc IC697MDL240 Discrete Input Module is a reliable and high-performance input module designed for the GE Series 90-70 PLC system. It provides 16 input points that detect ON/OFF signals from field devices such as switches, sensors, and relays. This module ensures accurate signal detection with optical isolation and noise immunity, making it suitable for a wide range of industrial automation and process control applications.
Key Features
-
16 discrete input points for ON/OFF signal detection
-
Input voltage range of 120 VAC for industrial applications
-
Optically isolated inputs to prevent noise interference
-
LED indicators for each input point for quick diagnostics
-
Compatible with GE Fanuc Series 90-70 PLC systems
-
Field wiring through removable terminal blocks
-
Designed for high reliability and long service life
-
Compact module design for efficient space utilization
Technical Specifications
| Specification | Details |
|---|---|
| Model | IC697MDL240 |
| Type | Discrete Input Module |
| System Compatibility | GE Fanuc Series 90-70 PLC |
| Number of Inputs | 16 points |
| Input Voltage Range | 120 VAC |
| Input Current | 7 mA typical at rated voltage |
| Isolation | Optical isolation per point |
| Input Impedance | 17 kΩ (typical) |
| Logic Type | Sinking |
| Indicators | LED per input channel |
| Power Requirements | +5 VDC, 0.15 A (typical) |
| Mounting Type | Standard Series 90-70 rack mount |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Dimensions | 200 × 40 × 150 mm |
| Weight | 0.34 kg |
Frequently Asked Questions (FAQ)
1. What is the primary function of the IC697MDL240 module?
It detects and processes 16 discrete ON/OFF signals from field devices for the GE Fanuc Series 90-70 PLC system.
2. What type of voltage does the module support?
It supports 120 VAC discrete input signals.
3. How many input channels does this module have?
The IC697MDL240 provides 16 independent input channels.
4. Are the inputs isolated?
Yes, each input point is optically isolated to prevent electrical noise interference.
5. What types of devices can be connected to the inputs?
Devices such as limit switches, push buttons, proximity sensors, and relays can be connected.
6. Does the module have LED indicators?
Yes, each input channel has a dedicated LED for status indication.
7. How is the module powered?
It operates using +5 VDC from the backplane, typically consuming 0.15 A.
8. Can it be installed in any Series 90-70 rack?
Yes, it can be mounted in any standard GE Fanuc 90-70 PLC rack.
Related GE Fanuc Modules
| Model | Description |
|---|---|
| IC697MDL340 | 32-Point Discrete Input Module (24 VDC) |
| IC697MDL241 | 120 VAC Isolated Input Module |
| IC697MDL250 | 16-Point Isolated Input Module (24 VDC) |
| IC697MDL340 | High-Density Input Module |
| IC697MDL940 | 120 VAC Input Module with Isolation |
| IC697MDL930 | 16-Point Input Module (DC Type) |
Popular GE Fanuc Models
| Model | Description |
|---|---|
| IC697CPX928 | High-performance Single-slot CPU Module |
| IC697CSE925 | CPU Module for Series 90-70 PLC systems |
| IC697HSC700 | High-speed Counter Module |
| IC697ALG320 | Analog Input Module |
| IC697MDL340 | 32-Point Discrete Input Module |
| IC697MDL240 | 16-Point Discrete Input Module (120 VAC) |
