Product Overview
The GE Fanuc IC697MDL241 Discrete Input Module is designed to interface field devices that send ON/OFF signals to the GE Series 90-70 PLC system. It provides 16 isolated input points, each capable of handling 120 VAC signals, making it ideal for industrial environments that require reliable detection of high-voltage discrete inputs.
Key Features
-
16 discrete input points for 120 VAC signal detection
-
Optically isolated inputs for enhanced noise immunity
-
LED indicators for each input point for status monitoring
-
Compatible with GE Fanuc Series 90-70 PLC systems
-
Modular design allowing easy installation and maintenance
-
Suitable for harsh industrial automation environments
-
Supports both normally open and normally closed input devices
-
High durability and long service life
Technical Specifications
| Specification | Details |
|---|---|
| Model | IC697MDL241 |
| Type | Discrete Input Module |
| System Compatibility | GE Fanuc Series 90-70 PLC |
| Number of Inputs | 16 points |
| Input Voltage Range | 120 VAC (nominal) |
| Input Current | 7 mA typical at rated voltage |
| Isolation | Optical isolation per channel |
| Input Impedance | 17 kΩ (typical) |
| Logic Type | Sinking |
| Indicators | LED per input channel |
| Power Requirements | +5 VDC, 0.15 A (typical) |
| Mounting Type | Standard Series 90-70 rack mount |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Dimensions | 200 × 40 × 150 mm |
| Weight | 0.34 kg |
Frequently Asked Questions (FAQ)
1. What is the main function of the IC697MDL241 module?
It detects discrete ON/OFF signals from field devices operating at 120 VAC and transmits the status to the PLC.
2. How many input channels does the module provide?
It provides 16 isolated input points.
3. What voltage range can the inputs handle?
The inputs are rated for 120 VAC nominal voltage.
4. Is optical isolation included?
Yes, each input channel has optical isolation to improve signal integrity and protect against electrical noise.
5. How are input statuses indicated?
Each input channel includes an LED indicator that lights up when the input is active.
6. What types of field devices can connect to this module?
Devices like push buttons, limit switches, relays, and proximity sensors can be connected.
7. What is the typical power requirement?
It requires +5 VDC at approximately 0.15 A from the PLC backplane.
8. What is the operating temperature range?
It operates reliably between 0 °C and +60 °C.
