Product Overview
The GE Fanuc IC752SPL013-BA Excitation Control Interface Panel is a critical component designed for generator excitation systems. It serves as the interface between the generator excitation control system and external field devices, enabling stable and precise regulation of generator field current and voltage. This interface panel provides monitoring, protection, and control functionalities, ensuring reliable operation of synchronous generators in demanding industrial and utility applications. Its robust design allows seamless integration with GE excitation systems and long-term performance in harsh environments.
Key Features
-
Designed for GE Excitation Control Systems
-
Provides interface for excitation control and protection circuits
-
Enables precise monitoring of field voltage and current
-
Supports relay and terminal connections for easy wiring
-
Built-in protection features for system safety and reliability
-
Rugged and compact design for industrial environments
-
Ensures long-term performance in generator applications
Technical Specifications
| Item | Specification |
|---|---|
| Model Number | IC752SPL013-BA |
| Manufacturer | GE Fanuc |
| Product Type | Excitation Control Interface Panel |
| Application | Generator excitation control and monitoring |
| System Compatibility | GE Excitation Systems (EX2100, EX2000, etc.) |
| Input Signals | Field voltage, field current, excitation feedback signals |
| Output Signals | Relay outputs, status signals |
| Communication | Designed for system interface via excitation control modules |
| Power Supply | Provided by excitation system (typical 24 VDC / system bus) |
| Protection Features | Overvoltage, overcurrent, and isolation protection |
| Operating Temperature | 0 °C to +65 °C |
| Storage Temperature | -40 °C to +85 °C |
| Dimensions | 160 x 160 x 120 mm |
| Weight | 0.8 kg |
| Mounting | Panel-mounted |
| Compliance | CE, RoHS, IEC standards |
Industry Applications
-
Power Generation – excitation control for synchronous generators
-
Utilities – stable power supply and generator reliability
-
Oil & Gas – power generation in process plants and offshore facilities
-
Petrochemical – generator excitation for continuous operation
-
Heavy Industry – steel plants, mining, and paper mills with large synchronous machines
Advantages
-
Ensures stable and reliable generator excitation control
-
Provides multiple monitoring and protection functions
-
Robust design for demanding industrial environments
-
Easy installation and integration with GE excitation systems
-
Enhances generator lifespan and reliability
Frequently Asked Questions (FAQ)
Q1: What is the function of the IC752SPL013-BA?
It serves as an interface panel for GE excitation systems, enabling control, monitoring, and protection of generator excitation.
Q2: Which systems is it compatible with?
It is typically used with GE EX2100 and EX2000 excitation control systems.
Q3: What signals does it handle?
It processes field voltage, field current, excitation feedback, and status/control signals.
Q4: Does it provide protective functions?
Yes, it includes overvoltage, overcurrent, and electrical isolation protection.
Q5: How is it powered?
It is powered by the excitation control system, typically via 24 VDC or internal bus power.
Q6: What type of connectors are used?
It uses terminal blocks and relay connectors for reliable field wiring.
Q7: What are the typical applications?
It is used for excitation control in synchronous generators for power plants and industrial facilities.
Q8: Can it be directly connected to field devices?
Yes, it provides the necessary interface for relays, sensors, and field circuits.
Q9: What is the operating environment?
It is designed for industrial environments with a temperature range of 0 °C to +65 °C.
Q10: What standards does it comply with?
It complies with CE, RoHS, and IEC standards for industrial safety and reliability.
