Product Overview
The GE IC200ALG430 is a highly versatile Analog Mixed Input Module designed for seamless integration into VersaMax PLC systems. This module is capable of processing both voltage (0-10V) and current (4-20mA) signals, providing robust solutions for a wide variety of industrial applications. The IC200ALG430 allows for precise signal conversion and real-time data acquisition, making it an essential component for monitoring and controlling systems in various industries.
This module features four input channels, offering flexibility in connecting multiple analog devices and sensors simultaneously. With a 16-bit resolution, it ensures highly accurate measurements for processes that require detailed analog feedback. Its compact DIN rail mountable design allows for easy installation in a range of industrial settings, including control cabinets and electrical panels.
The IC200ALG430 is ideal for industries such as chemical processing, HVAC, water treatment, and manufacturing, where accurate and reliable analog data is essential for optimizing operations.
Product Specifications
| Specification | Details |
|---|---|
| Model Number | IC200ALG430 |
| Channels | 4 Analog Mixed Input Channels |
| Signal Input Types | Voltage (0-10V), Current (4-20mA) |
| Input Resolution | 16-bit resolution |
| Power Supply | 24V DC |
| Mounting Type | DIN Rail Mountable |
| Dimensions | 110 x 66.8 x 50 mm |
| Weight | 0.159 kg |
| Status Indicators | Power, Error, and Status LEDs |
Applications of the GE IC200ALG430
The IC200ALG430 is used in a wide variety of industrial and commercial applications, particularly where precise analog data is needed for process control and monitoring. Its ability to handle both voltage and current signals makes it highly adaptable across different systems and industries.
-
Industrial Process Control: The IC200ALG430 is used to interface with temperature sensors, pressure transmitters, and flow meters, providing real-time data for process automation and control systems.
-
Energy Management: Used to monitor energy consumption, the module helps optimize efficiency and performance in industrial facilities, power plants, and smart grids.
-
HVAC Systems: The module is essential for temperature regulation and air quality monitoring in commercial buildings and manufacturing plants, ensuring comfort and compliance with environmental standards.
-
Environmental Monitoring: Employed in water treatment, waste management, and pollution control, the IC200ALG430 ensures precise data acquisition for environmental safety.
-
Factory Automation: The module is used in robotics, assembly lines, and automated testing systems, providing accurate feedback for machine control and process optimization.
-
Research and Development: The IC200ALG430 is also used in R&D labs to collect accurate data from various sensors and ensure optimal performance of experimental systems.
Advantages of the GE IC200ALG430
-
Dual Signal Support: The IC200ALG430 can process both voltage (0-10V) and current (4-20mA) signals, allowing it to interface with a wide variety of analog devices and sensors.
-
High-Precision Data Conversion: With 16-bit resolution, the IC200ALG430 ensures that input signals are accurately converted into digital data for precise control and monitoring.
-
Flexible and Scalable: The 4 channels provided by the IC200ALG430 make it highly flexible, accommodating multiple input devices and easily scaling for larger systems.
-
Easy Integration: The IC200ALG430 is designed for VersaMax PLCs, ensuring simple integration and compatibility with existing systems.
-
Real-Time Data Acquisition: The module ensures that real-time data is available, allowing operators to make immediate adjustments to the system based on the most current information.
-
Compact and Robust: The compact design, combined with DIN rail mounting, makes the IC200ALG430 ideal for installation in tight spaces, while its durable construction ensures reliable performance in harsh industrial environments.
-
Cost-Effective Solution: The module provides high-quality performance at an affordable price, making it a cost-effective solution for industries requiring analog data acquisition and control.
FAQ
1. What types of signals does the IC200ALG430 support?
The IC200ALG430 supports voltage (0-10V) and current (4-20mA) signals, offering flexibility to interface with a wide variety of analog sensors and devices.
2. How many input channels does the IC200ALG430 have?
The module features 4 input channels, which allow it to handle multiple signals simultaneously.
3. What is the resolution of the IC200ALG430?
The IC200ALG430 has a 16-bit resolution, ensuring high-accuracy data conversion for both voltage and current inputs.
4. Can the IC200ALG430 be used in industrial process control?
Yes, the IC200ALG430 is ideal for process control applications, including temperature, pressure, and flow monitoring.
5. Does the IC200ALG430 support both current and voltage signals?
Yes, it can process both voltage (0-10V) and current (4-20mA) signals, making it highly versatile for different applications.
6. How is the IC200ALG430 mounted?
The module is DIN rail mountable, making it easy to install in control cabinets or industrial panels.
7. Can the IC200ALG430 be used for environmental monitoring?
Yes, the IC200ALG430 is commonly used in water treatment, waste management, and pollution control applications, providing precise data for environmental safety.
8. Is the IC200ALG430 compatible with other GE PLC systems?
The IC200ALG430 is designed for use with VersaMax PLCs, ensuring seamless integration with these systems.
9. How does the IC200ALG430 improve accuracy in data acquisition?
The module provides 16-bit resolution for high-accuracy signal conversion, ensuring that the data is as precise as possible for control and monitoring systems.
10. What are the primary industries that use the IC200ALG430?
The IC200ALG430 is widely used in industries like chemical processing, HVAC, manufacturing, water treatment, and energy management.
