Product Introduction
The GE IC200CHS014 VersaMax I/O Insert Box T-Type is an integral component of the VersaMax I/O system designed to offer easy and reliable connections for industrial automation applications. The T-Type insert box is used to connect input and output modules with the VersaMax PLC, providing an efficient and flexible I/O solution for various industrial processes.
This insert box is ideal for applications where space optimization and secure wiring are crucial, offering a compact and modular design. With its T-type configuration, it facilitates efficient wiring, ensuring quick installations and reliable performance in industrial control systems.
Product Specifications
Here are the key specifications for the GE IC200CHS014 VersaMax I/O Insert Box T-Type:
| Specification | Value |
|---|---|
| Model | IC200CHS014 |
| Type | VersaMax I/O Insert Box T-Type |
| Dimensions (L x W x H) | 110.5 x 105.4 x 70 mm |
| Weight | 0.22 kg |
| Mounting Type | DIN Rail Mounting |
| Material | High-quality plastic |
| Connector Type | Spring-type terminal for quick wiring |
| Terminal Type | 16-pin screw terminals |
| Number of Terminals | 16 I/O connections |
| Operating Temperature Range | -20°C to 60°C |
| Compatibility | Compatible with VersaMax I/O modules |
Applications
The GE IC200CHS014 VersaMax I/O Insert Box T-Type is suitable for a variety of industrial automation applications:
-
Industrial Automation: The insert box connects a range of input/output devices such as sensors and actuators to VersaMax PLCs, enabling seamless automated control systems.
-
Control Systems: It is ideal for control panel applications where space is limited, providing a modular solution for I/O expansion in industrial systems.
-
Process Control Systems: The insert box is used in process control applications, linking sensors and actuators to process controllers for precise control of industrial processes.
-
Manufacturing: Perfect for manufacturing automation, the IC200CHS014 provides quick installation and reliable connections for automated production lines.
-
Building Automation: Used in HVAC, lighting control, and other building automation systems, the insert box helps manage inputs and outputs for efficient control of buildings.
-
Energy Management Systems: It supports energy monitoring and management systems, integrating energy meters with VersaMax PLCs for data collection and optimization.
Advantages
-
Compact Design: The IC200CHS014 has a compact size (110.5 x 105.4 x 70 mm), making it ideal for installations in space-constrained environments without compromising performance.
-
Spring-Type Connection: The spring-type terminal ensures tool-free and secure connections, reducing installation time and the risk of faulty wiring.
-
Flexible Integration: The T-type configuration enables quick and efficient connections between the VersaMax PLC and various input/output devices, offering flexibility in design and layout.
-
Durable and Robust: Made from high-quality plastic, the insert box is built to withstand demanding industrial environments, providing long-lasting performance.
-
DIN Rail Mounting: The DIN rail mounting option allows for quick, stable, and secure installation, which is particularly useful in control panels and industrial cabinets.
-
Wide Temperature Range: With an operating temperature range from -20°C to 60°C, the IC200CHS014 is suitable for use in a variety of industrial conditions.
-
16-Terminal Support: It supports up to 16 I/O terminals, providing ample capacity for a wide range of input and output devices.
FAQ
-
What is the purpose of the GE IC200CHS014 I/O Insert Box?
The IC200CHS014 is used to connect input/output devices to VersaMax PLC systems, enabling efficient data exchange between field devices and control systems. -
What is the difference between the T-type insert box and other I/O modules?
The T-type insert box provides a compact and modular design, allowing for easy and quick wiring connections, unlike other systems that may require more complex configurations. -
What are the advantages of the spring-type terminal design?
The spring-type terminals allow for tool-free installation, making the wiring process faster and reducing the chance of installation errors. -
How many I/O connections can the IC200CHS014 support?
The IC200CHS014 supports up to 16 I/O connections, which is suitable for many standard industrial automation applications. -
What types of devices can be connected to the IC200CHS014?
It supports a variety of digital and analog input/output devices, including sensors, actuators, switches, and other field devices. -
Is the IC200CHS014 compatible with all VersaMax I/O modules?
Yes, the IC200CHS014 is compatible with all VersaMax I/O modules, making it a flexible solution for a wide range of applications. -
How does the T-type configuration help in wiring?
The T-type configuration simplifies wiring by organizing input/output terminals efficiently, allowing for quick and clear connections to field devices. -
Can the IC200CHS014 be used in outdoor applications?
While it is designed for indoor industrial applications, it can be used in outdoor environments if housed in an appropriate enclosure to protect it from harsh weather conditions. -
What is the mounting method for the IC200CHS014?
The IC200CHS014 is designed for DIN rail mounting, which ensures stable and secure installation in control panels. -
What protection features are built into the IC200CHS014?
The IC200CHS014 is designed to be durable and reliable, with short-circuit protection features to prevent damage to connected devices.
