Product Introduction
The GE IC200CHS101 Disconnectable Insertion I/O Terminal, Main Base, is a reliable and essential component for VersaMax I/O systems. It is specifically designed to facilitate easy connections for input/output devices such as sensors, actuators, and relays to the VersaMax PLC modules. The disconnectable feature allows users to conveniently remove and replace modules without affecting the rest of the system, making it extremely beneficial in maintenance scenarios.
This main base terminal provides a stable foundation for VersaMax I/O systems, offering superior performance and high-level protection for both digital and analog signals. Its modular design ensures that users can customize their control systems according to specific application needs. The secure screw terminals ensure safe connections, while the compact size of the device makes it suitable for installations in tight spaces within control panels and enclosures.
Product Specifications
Here are the key specifications for the GE IC200CHS101 Disconnectable Insertion I/O Terminal, Main Base:
| Specification | Value |
|---|---|
| Model | IC200CHS101 |
| Type | Disconnectable Insertion I/O Terminal |
| Dimensions | 115 x 126 x 65 mm |
| Weight | 1.36 kg |
| Mounting | DIN Rail Mounting |
| Terminal Type | Screw Terminal |
| Input/Output Capability | Supports both digital and analog I/O |
| Number of Terminals | Up to 32 inputs/outputs |
| Operating Temperature | -20°C to 60°C |
| Power Supply | Powered through VersaMax I/O Modules |
| Protection | Relay-based protection for inputs/outputs |
| Connection Type | Screw Terminal Block for Wiring |
Applications
The GE IC200CHS101 Disconnectable Insertion I/O Terminal is designed for use in various industrial and automation applications:
-
Industrial Automation: It is used to connect input/output devices such as sensors, switches, and actuators to VersaMax PLC systems, enabling automated control in factory settings.
-
Manufacturing Systems: In manufacturing and production lines, the terminal facilitates quick disconnection and reconnection of input/output devices for maintenance or system upgrades.
-
Process Control: It is crucial in process control systems where accurate and stable communication between sensors, actuators, and controllers is required.
-
Building Automation: The terminal serves as a critical component in connecting HVAC systems, security systems, and lighting control systems with the central VersaMax PLC.
-
Machine Control Systems: The terminal ensures a secure and efficient connection between PLC modules and machine-level devices such as motors and conveyors.
-
Energy Management: It provides integration for energy meters and monitoring systems into centralized energy management systems, optimizing energy usage in large facilities.
Advantages
-
Disconnectable Feature: The key advantage of the IC200CHS101 is the disconnectable feature that allows for quick removal and replacement of components without disturbing the rest of the system, reducing downtime.
-
Versatile I/O Support: The terminal can handle both digital and analog I/O signals, making it suitable for a wide range of industrial applications.
-
Compact Design: The compact design (115 x 126 x 65 mm) ensures that the terminal can be installed in constrained spaces, providing more flexibility for panel layouts.
-
Relay Protection: The terminal is equipped with relay-based protection, ensuring that connected devices are protected from overcurrent or overvoltage conditions, enhancing system reliability.
-
Durability: With an operating temperature range from -20°C to 60°C, the terminal is designed to perform reliably even in harsh industrial environments.
-
Secure Wiring: The screw terminal design ensures that wiring connections are firm and reliable, preventing any accidental disconnections.
-
Modular Expansion: The modular design allows the terminal to be expanded with additional VersaMax I/O modules, making it ideal for systems requiring high scalability.
FAQ
-
What is the purpose of the GE IC200CHS101 Disconnectable Insertion I/O Terminal?
The IC200CHS101 is used to connect input/output devices to VersaMax PLC systems, providing flexible and secure connections with a disconnectable feature for easy maintenance. -
How does the disconnectable feature benefit users?
The disconnectable feature allows users to remove or replace input/output modules without affecting the overall system, making maintenance easier and reducing downtime. -
How many I/O terminals can the IC200CHS101 handle?
The IC200CHS101 can handle up to 32 I/O connections, depending on the configuration of connected devices. -
What type of protection is available for the connected devices?
The terminal provides relay-based protection for both inputs and outputs, ensuring safe operation and protection against electrical faults. -
What is the power supply requirement for the IC200CHS101?
The terminal is powered through the VersaMax I/O modules, providing a 24 VDC power supply to the device and any connected field devices. -
What types of signals does the IC200CHS101 support?
The IC200CHS101 supports both digital and analog signals, providing flexibility for various industrial applications. -
How is the IC200CHS101 mounted?
The terminal is designed for DIN rail mounting, which allows for secure and easy installation in control panels and industrial enclosures. -
Can I expand the IC200CHS101 system?
Yes, the IC200CHS101 is part of a modular system and can be expanded with additional VersaMax I/O modules to suit more complex or larger systems. -
What is the operating temperature range of the IC200CHS101?
The terminal operates in an environment with a temperature range from -20°C to 60°C, making it suitable for industrial settings with varying environmental conditions. -
How does the screw terminal block improve the I/O system?
The screw terminal block ensures secure and reliable connections, preventing loose wires and reducing the risk of electrical failures in the system.
