Product Overview
The GE IC200MDD842 is a versatile VersaMax Discrete Mixed I/O Module, combining both digital input and output functions into a single module. This module is designed for industrial applications where space-saving and flexibility are essential. By integrating both input and output channels, the IC200MDD842 significantly reduces wiring complexity and enhances system performance, making it ideal for compact control systems in automation environments. It is part of the VersaMax Micro series, known for reliability, high speed, and ease of integration with PLC systems.
Product Specifications:
| Specification | Details |
|---|---|
| Model | IC200MDD842 |
| Type | Discrete Mixed I/O Module |
| Compatibility | VersaMax Micro PLC |
| Input Points | 8 Digital Inputs |
| Output Points | 8 Digital Outputs |
| Dimensions (W x H x D) | 133.4 x 85.9 x 69.1 mm |
| Weight | 0.14 kg |
| Power Supply | 5V DC |
| Operating Temperature | 0°C to 60°C |
| Communication Protocol | Modbus/TCP |
| Current Rating | 2 A per Output |
| Mounting Type | DIN Rail |
| Protection | Overcurrent and Overvoltage Protection |
| LED Indicators | Power, Input, Output Status |
Product Applications:
The GE IC200MDD842 is widely used in industrial automation applications, where both digital inputs and outputs are required in a single, compact unit. Common applications include:
-
Industrial Automation Systems: Used to interface with sensors, switches, and actuators in PLC-controlled systems for automation tasks like assembly lines and packaging machines.
-
Monitoring and Control: The module can monitor various devices such as temperature sensors, proximity sensors, and switches while controlling actuators and relays for automated responses.
-
Process Automation: Ideal for use in processes that require both input from devices like level switches and output to devices like solenoids or valves.
-
Data Acquisition: Collecting input data from external devices for processing and transmitting output signals to other equipment.
Product Advantages:
-
Space-Efficient Design: The IC200MDD842 is designed to save space, reducing the need for multiple I/O modules in tightly packed control panels or distributed systems.
-
Dual Functionality: The module combines both digital inputs and outputs, reducing wiring complexity and streamlining system architecture.
-
High Current Capacity: With a current rating of up to 2 A per output, the module is capable of controlling powerful devices, making it suitable for a range of industrial applications.
-
Reliable Communication: Uses Modbus/TCP protocol for high-speed communication, ensuring reliable real-time data transmission between the module and the PLC.
-
Easy Installation: Mounts on a DIN rail, which is the standard for industrial control devices, making it easy to install in existing systems.
-
LED Indicators: Equipped with LED status indicators for both inputs and outputs, allowing for quick diagnostics and troubleshooting without the need for external tools.
FAQ:
1. How does the IC200MDD842 handle mixed I/O?
The IC200MDD842 integrates both digital inputs and outputs in a single module. It is designed to simplify wiring by reducing the number of modules required, while still providing both input and output capabilities.
2. Can the IC200MDD842 be used with other GE automation products?
Yes, the IC200MDD842 is fully compatible with VersaMax Micro PLCs and integrates seamlessly into the VersaMax and other GE automation systems that support Modbus/TCP communication.
3. How does the module handle overcurrent situations?
The IC200MDD842 includes overcurrent protection on the output channels. If an output device draws too much current, the module will protect itself and the connected devices by cutting power to the affected channel.
4. What is the power supply requirement for the IC200MDD842?
The IC200MDD842 operates with a 5V DC power supply, which is standard for many VersaMax series modules.
5. How many outputs can be controlled simultaneously?
The module has 8 digital outputs, and each output can handle up to 2A of current, allowing it to control a range of industrial devices such as relays, valves, or motors.
6. What communication protocols does the IC200MDD842 support?
The IC200MDD842 supports Modbus/TCP, a widely used industrial communication protocol for controlling devices and transferring data in real-time.
7. Is the IC200MDD842 suitable for outdoor environments?
The module is intended for indoor use only, and should be protected from environmental elements such as moisture, dust, and extreme temperatures to ensure optimal performance.
8. How is the module mounted?
The IC200MDD842 mounts on a DIN rail, a standard mounting system used for industrial automation devices, ensuring easy installation and integration.
9. Can the IC200MDD842 handle high-speed applications?
Yes, the IC200MDD842 supports real-time data transmission with the Modbus/TCP protocol, making it suitable for high-speed applications such as real-time monitoring and control in industrial systems.
10. What types of digital devices can be connected to the IC200MDD842?
You can connect a wide variety of digital input devices such as switches, sensors, and proximity detectors, as well as digital output devices such as relays, actuators, and solenoids.
