Product Introduction
The GE IC200UEO116 VersaMax Micro Expansion Module is an output module designed for VersaMax Micro PLC systems. It extends the system’s capabilities by adding 16 relay outputs to the existing configuration, enabling the control of external devices such as motors, valves, and actuators. With its compact design, the IC200UEO116 is ideal for applications that require a high degree of flexibility and scalability within a small space.
This module is easy to integrate into a VersaMax Micro PLC system, and its plug-and-play installation minimizes setup time. The IC200UEO116 provides reliable, cost-effective expansion, especially in applications such as automation, machine control, and monitoring systems where additional output points are needed.
Product Specifications
Below are the key specifications for the GE IC200UEO116 VersaMax Micro Expansion Module:
| Specification | Value |
|---|---|
| Model | IC200UEO116 |
| Type | VersaMax Micro Expansion Output Module |
| Dimensions | 95 x 90 x 76 mm |
| Weight | 1.36 kg |
| Number of Outputs | 16 Relay Outputs |
| Output Voltage Range | 10-30 VDC |
| Input Voltage Range | 10-30 VDC |
| Relay Type | SPDT (Single-Pole Double-Throw) |
| Relay Rating | 2A @ 30VDC |
| Operating Temperature | -20°C to 60°C |
| Mounting | DIN Rail Mounting |
| Communication Protocol | RS-485 Modbus RTU |
Applications
The GE IC200UEO116 VersaMax Micro Expansion Module is designed to meet the growing need for compact, expandable control systems in a wide range of industrial applications. Here are some key applications:
-
Machine Automation: The module provides essential relay outputs for controlling machinery, including actuators, solenoids, and motors.
-
Industrial Control Systems: It is commonly used in industrial environments where additional I/O points are needed for equipment control and monitoring.
-
Process Control Systems: The module expands the capabilities of VersaMax Micro PLC systems, enabling precise control over processes that require additional output points.
-
Building Automation: Used for controlling HVAC systems, lighting, and other building management functions.
-
Packaging Systems: It enables the control of various devices in packaging lines, such as conveyor belts, sensors, and pneumatic systems.
-
Energy Management: Expands the capabilities of energy control systems, allowing for more efficient management of electrical distribution and load balancing.
Advantages
-
High Flexibility: The IC200UEO116 offers 16 relay outputs, providing more flexibility in controlling external devices, actuators, and sensors.
-
Compact and Efficient: With its compact design, it allows for expansion in tight spaces without sacrificing performance, making it ideal for applications with space constraints.
-
Easy Integration: Designed for seamless integration with VersaMax Micro PLC systems, the IC200UEO116 can be easily added to your existing control system with minimal setup.
-
Reliable Performance: The relay outputs in this module are capable of switching up to 2A at 30VDC, providing reliable and consistent control of external devices.
-
Cost-Effective Expansion: This module provides a cost-effective solution for expanding I/O capabilities without needing a more expensive, larger PLC system.
-
Wide Temperature Range: It operates effectively in temperatures ranging from -20°C to 60°C, ensuring reliable performance in various industrial environments.
-
Robust Communication: The RS-485 Modbus RTU communication protocol ensures reliable data transmission and system integration, even in harsh industrial conditions.
FAQ
-
What is the purpose of the GE IC200UEO116 VersaMax Micro Expansion Module?
The IC200UEO116 provides 16 relay outputs for controlling external devices such as motors, solenoids, and actuators, expanding the capabilities of a VersaMax Micro PLC system. -
How does the IC200UEO116 module communicate with the PLC?
The module communicates with the VersaMax Micro PLC using the RS-485 Modbus RTU communication protocol, ensuring reliable data transmission. -
What is the relay type used in the IC200UEO116?
The module features SPDT (Single-Pole Double-Throw) relays, which are ideal for switching various devices such as motors, lights, and valves. -
Can the IC200UEO116 module be used in systems other than VersaMax PLCs?
No, the IC200UEO116 is designed specifically for VersaMax Micro PLC systems and may not be compatible with other brands or systems. -
What is the output voltage range for the IC200UEO116?
The module supports an output voltage range of 10-30 VDC, making it compatible with a wide range of industrial devices. -
What is the maximum current rating for the relay outputs?
Each relay output is capable of handling a maximum of 2A at 30VDC, providing sufficient capacity for typical control applications. -
How is the IC200UEO116 installed?
The module is designed for DIN rail mounting, allowing for easy and secure installation in control panels or machinery. -
What type of devices can I control using the IC200UEO116?
You can control a variety of devices including motors, actuators, solenoids, valves, and other digital equipment used in industrial automation. -
Is the IC200UEO116 module suitable for extreme temperatures?
Yes, the module operates within a temperature range of -20°C to 60°C, making it suitable for a variety of industrial environments. -
Can I use multiple IC200UEO116 modules in a single PLC system?
Yes, multiple IC200UEO116 modules can be added to the VersaMax Micro PLC system, depending on the system’s configuration and requirements.
Related Models from the Same Series
Here are six other models from the VersaMax Micro PLC series that are compatible with or related to the IC200UEO116:
| Model | Description |
|---|---|
| IC200CPU001 | VersaMax Micro PLC CPU Module |
| IC200UDR001 | VersaMax Micro PLC Power Supply |
| IC200ALG260 | VersaMax Analog Input Module |
| IC200MDL640 | VersaMax Digital Output Module |
| IC200MDL650 | VersaMax Digital Input Module |
| IC200CMM002 | VersaMax Communication Module |
