Product Introduction
The GE IC660EBA026 I/O Block Electronic Assembly is a vital component of GE’s Genius I/O family, designed for use in robust industrial automation systems. As an electronics assembly for Genius discrete I/O blocks, the IC660EBA026 is specifically engineered for compatibility with 115V AC input/output terminals. This unit is part of a modular system where the electronics are separate from the terminal base, offering flexibility, ease of maintenance, and tailored application deployment.
With advanced diagnostics, configurable I/O points, and integration into distributed control architectures, this module is an ideal solution for applications that demand high-voltage signal processing, centralized intelligence, and reliable field device communication. It communicates over the Genius I/O bus, which is well-known for its deterministic real-time performance and noise immunity.
Product Specifications
Parameter | Details |
---|---|
Model | IC660EBA026 |
Manufacturer | GE Automation & Controls |
Series | Genius I/O |
Product Type | I/O Block Electronic Assembly |
Compatible Terminal Base | IC660TBA026 (or equivalent) |
I/O Signal Type | Discrete AC (115V) |
Input Voltage | 90 – 132 VAC |
Output Voltage | 90 – 132 VAC |
Frequency Range | 47 – 63 Hz |
Power Consumption | Typically 3.5W |
Communication Interface | Genius I/O Serial Bus (Shielded Twisted Pair) |
Configuration Method | Hand-held Monitor or Programming Software |
Diagnostic Features | LED indicators, open wire, overload, short circuit |
Status Indicators | LEDs for each I/O channel |
Mounting Method | Panel Mount (with terminal base) |
Environmental Rating | Industrial Grade |
Operating Temperature | 0°C to 60°C (32°F to 140°F) |
Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
Relative Humidity | 5% to 95% (non-condensing) |
Dimensions (H x W x D) | 177 x 112 x 63 mm |
Weight | 0.898 kg |
Product Applications
-
Industrial Machinery Control: Used to interface high-voltage discrete devices like motors, valves, and solenoids.
-
Process Plants: Suitable for on/off control of actuators and feedback from sensors in environments with AC power lines.
-
Packaging and Assembly Lines: Integrates into systems with AC-driven field devices and relay-based outputs.
-
Energy Distribution Facilities: Used in monitoring and control of switchgear and substations.
-
Transportation Systems: Applied in railway signaling, traffic barriers, and tunnel automation systems.
-
Manufacturing Automation: Ideal for interfacing with AC-powered field equipment across discrete manufacturing sectors.
Product Advantages
-
Modular Construction: Separate electronics and terminal base simplify replacement, upgrade, and maintenance.
-
Designed for High Voltage: Supports 115V AC input/output applications directly without external interfacing.
-
Built-in Diagnostics: Real-time monitoring of wire faults, overloads, and communication issues reduces troubleshooting time.
-
Visual Status Feedback: Each I/O channel includes LED indicators to show operational status instantly.
-
Wide Compatibility: Works seamlessly with Genius-compatible controllers and host systems like GE Series 90-70, 90-30, and RX3i.
-
Industrial-Grade Reliability: Withstands harsh conditions including electrical noise, temperature fluctuation, and vibration.
Frequently Asked Questions (FAQ)
-
What is the GE IC660EBA026 used for?
It serves as the electronics component of a Genius I/O block for handling 115V AC discrete signals in industrial control systems. -
Can the module be configured without software?
Yes, configuration is possible using a GE Genius hand-held monitor, though software tools are also supported. -
Is this module suitable for analog signals?
No, this specific model is designed only for discrete AC input/output. For analog, other Genius models should be used. -
How does it handle electrical faults?
The module includes built-in diagnostics for detecting open wires, short circuits, and overloads on each channel. -
What base does this module require?
It must be paired with a compatible terminal base, such as IC660TBA026, to function properly. -
What kind of devices can I connect to it?
It supports AC-powered sensors, relays, solenoids, and other high-voltage field devices. -
Can it be replaced while powered on?
No, the module should be powered down before replacement to avoid potential damage or communication faults. -
How many I/O points are supported?
The number of I/O points depends on the terminal base it is paired with, typically 16 channels. -
Is the Genius bus still widely supported?
Yes, especially in legacy and long-life industrial installations. Many current GE systems maintain compatibility. -
What makes this different from a full I/O block?
This is the electronics-only portion. A full block includes both the electronics and the terminal base for complete operation.
