The GE IC660TBA026 Terminal Assembly is a field wiring component designed for use with GE’s Genius I/O discrete and analog blocks. As part of the GE Fanuc IC660 series, this terminal assembly serves as the physical interface between the I/O block and field wiring, ensuring safe, efficient, and organized electrical connections in industrial control systems.
Designed for demanding industrial environments, the IC660TBA026 features robust construction, durable screw terminals, and compatibility with a range of block types. It plays a critical role in distributed control systems by reducing wiring complexity and ensuring long-term operational stability. Its simple, modular installation makes it a preferred choice for system integrators and OEMs alike.
Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | IC660TBA026 |
| Product Type | Terminal Assembly for Genius I/O |
| I/O Type | Compatible with discrete/analog blocks |
| Number of Terminals | 24 screw-type terminals |
| Terminal Style | Screw compression |
| Voltage Rating | Up to 250 VAC / 125 VDC (dependent on I/O block) |
| Current Rating | Up to 2 A per terminal |
| Insulation Resistance | >100 MΩ |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Enclosure Type | Requires enclosure for protection |
| Mounting Style | DIN Rail or Panel Mount |
| Certifications | UL, CE, CSA |
| Dimensions (W x H x D) | 111 x 82 x 56 mm |
| Weight | 0.9 kg |
Product Applications
The IC660TBA026 is commonly used in a wide variety of industrial sectors, especially in distributed I/O systems where space, reliability, and clarity in wiring are paramount.
-
Industrial Automation Lines
For connecting sensors, push-buttons, switches, and indicators to Genius I/O blocks. -
Power Generation Plants
Interfaces between control panels and field instrumentation for turbines, breakers, and transformers. -
Water/Wastewater Management
Manages remote I/O blocks for pump control, tank levels, and flow monitoring. -
Pharmaceutical and Food Processing
Ensures clean wiring layout and modular system design in regulated environments. -
Material Handling Systems
Used in conveyors, robotics, and sorting systems for signal routing and machine control. -
Oil & Gas Industry
Field connections in remote installations, offering rugged, vibration-resistant terminal points.
Product Advantages
-
Reliable Field Wiring Interface
24 terminals provide dependable and tight connections using screw compression design. -
Broad Compatibility
Works seamlessly with various GE Genius I/O blocks (discrete and analog). -
Quick Installation
Terminal layout simplifies wiring and reduces commissioning time. -
Industrial Grade Durability
Operates across wide temperature and humidity ranges, ensuring field reliability. -
Maintenance Friendly
Easy identification and removal without disrupting existing wiring. -
Modular & Scalable
Easily expandable for systems requiring multiple terminal assemblies. -
Safe & Certified
Meets international safety certifications (UL, CE, CSA). -
Compact Footprint
Designed to conserve control panel space without compromising access. -
Cost-Effective
Minimizes downtime and wiring errors, reducing maintenance costs over time. -
Secure Mounting Options
Can be mounted both on panels and DIN rails, supporting various installation environments.
Frequently Asked Questions (FAQ)
-
Q: What is the function of the IC660TBA026 Terminal Assembly?
A: It provides terminal connections between GE Genius I/O blocks and field devices. -
Q: Is it compatible with analog input modules?
A: Yes, it is compatible with both discrete and analog blocks within the IC660 series. -
Q: How many terminals does it include?
A: It includes 24 screw-type terminals for field wiring. -
Q: What kind of mounting options are supported?
A: It can be mounted on a DIN rail or a panel. -
Q: What is the maximum voltage it can handle?
A: It supports up to 250 VAC or 125 VDC, depending on the connected I/O block. -
Q: Can it be used in high-vibration environments?
A: Yes, its secure screw terminals and solid construction make it vibration-resistant. -
Q: Does it include wiring labels?
A: Yes, each terminal point is labeled for easy and error-free installation. -
Q: What is the operating temperature range?
A: It operates from 0°C to 60°C. -
Q: Is it suitable for outdoor installation?
A: Only when placed inside a proper industrial-rated enclosure. -
Q: Is this terminal assembly hot-swappable?
A: No, power must be turned off before replacing or removing the unit.
