System Integration Overview
The GE IC670GBI102 is a Bus Interface Module used within the IC670 / RX3i distributed I/O architecture. As a key component in multi-rack or remote I/O networks, it provides a stable communication link between the primary controller and expansion bases.
From a system integration standpoint, the IC670GBI102 ensures synchronized data exchange, predictable bus timing, and consistent performance across extended wiring distances. It is often deployed in applications where a distributed architecture reduces panel density and supports modular expansion without redesigning the main control platform.
Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | IC670GBI102 |
| Brand | GE / Fanuc |
| Module Type | Bus Interface Module |
| Primary Function | Communication bridge between IC670 backplane and controller network |
| Supported Protocols | IC670 proprietary bus communication |
| Ports | Serial communication interface (RS-485–based architecture) |
| Backplane Interface | Direct IC670 chassis slot connection |
| Addressing | DIP switch configurable |
| Diagnostics | Status and communication LEDs |
| Power Source | Supplied through the IC670 chassis |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | –40°C to +85°C |
| Dimensions (H × W × D) | ≈ 110 mm × 35 mm × 120 mm |
| Weight | ≈ 0.50 kg |
| Installation | Slot-mounted onto any IC670-compatible chassis |
Applications / Use Scenarios
-
Multi-rack IC670 distributed I/O architectures
-
Expansion of RX3i systems requiring additional remote I/O panels
-
Industrial networks requiring deterministic communication across multiple bases
-
Retrofit projects upgrading older GE Fanuc architectures with modular extensions
-
High-reliability environments where stable backplane communication is essential
Advantages / Engineering Benefits
-
Reliable communication bridging for distributed I/O systems
-
Simplified network expansion without major PLC reconfiguration
-
DIP-switch addressing enables straightforward commissioning
-
LED diagnostics assist with alignment, wiring checks, and fault tracing
-
Stable bus timing ensures synchronized I/O updates across multiple racks
-
Rugged design supports long-term operation in high-vibration industrial areas
